Brand New Ms8218 Digital Voltmeter 50000 Count

US $150.00

  • Santa Clara, California, United States
  • Jan 29th
FOR SALE, Brand new MS8218 digital voltmeter. High accuracy 50000 count DMM by Huayi. Yellow front panel. FEATURES •50000 count measurement •Auto/Manual Range •ACV and DCV measurements up to 1000V •DC measurement accuracy 0.03% •0.01? resistance and 1µV voltage resolution •Voltage/Current frequency measurement •Logic frequency/duty cycle measurement •Capacitance measurement 0.01nf to 5000µF •AC/DC true RMS measurement/dBm measurement •MAX/MIN/MAX-MIN and Relative value measurement •Data hold/Back light/Auto off •USB interface and PC Windows software •Automatic software calibration •Full overload protection •Low battery indication •Insulation performance 1000V CAT III SPECIFICATIONS DCV: 50mV/500mV/5V/50V/500V/1000V ±0.03% ACV: 50mV/500mV/5V/50V/500V/1000V ±0.5% DC Current: 500µA/5000µA/50mA/500mA/5A/10A ±0.15% AC Current: 500µA/5000µA/50mA/500mA/5A ±0.75%, 10A±0.15% Resistance: 500?/5k?/50k?/500k?/5M?±0.1%, 50M?±0.5% Capacitance: 50nF/500nF/5µF/50µF±1%, 500µF/5000µF±2% Diode: 2.5V±1% Duty cycle: 5Hz ~ 500kHz Range: 10% ~ 90% Logic frequency: 5Hz ~ 5MHz±0.006%, Vpp 2 ~ 5V square wave Linear frequency: 10Hz ~ 200kHz±0.006% Sensitivity: lowest 100mV Display: LCD size 44mm x 70mm Weight: Approx. 600g Size: 200mm x 100mm x 40mm Battery: 6 x 1.5V (AAA Type) Specifications Range Accuracy MS8218 DC Voltage 50mV/500mV/5V/50V/500V/1000V ±0.03% AC Voltage 50mV/500mV/5V/50V/500V/1000V ±0.5% DC Current 500µA/5000µA/50mA/500mA/5A 10A ±0.15% ±0.75% AC Current 500µA/5000µA/50mA/500mA/5A/10A ±0.75% Resistance 500?/5k?/50k?/500k?/5M? 50M? ±0.1% ±0.5% Capacitance 50nF/500nF/5µF/50µF 500µF/5000µF ±1.0% ±2.0% Diode 2.5V ±1.0% Duty cycle 5Hz ~ 500kHz -- Range 10% ~ 90% -- Logic Frequency 5Hz ~ 5MHz, Vpp 2 ~ 5V square wave ±0.006% Linear Frequency 10Hz ~ 200kHz ±0.006% Sensitivity Lowest 100mV -- Feature Display 50,000 Count USB infrared interface ? Calibration by PC ? Full overload protection ? Low battery indication ? Security shell Secondary injection Auto/Manual range ? Data hold ? Diode test ? Max/Min ? Continuity ? Back light ? General Display 44 x 70mm LCD Power supply 6 x 1.5V AAA Weight Approx 600g Size 200mm x 100mm x 40mm Safety Rating CE CAT.III 1000V CAT.IV 600V RoHS
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Huayi
Country/Region of Manufacture China
Model MS8218
