B&r Acopos 1640 8v1640.00-2 Servo Drive 3x 400-480 V, 64 A, 54 Kva 8ac121.60-1

US $1,375.00

Novi, Michigan, United States
Jun 9th

Open on mobile:
QR code

B&R ACOPOS 1640 8V1640.00-2 SERVO DRIVE 3x 400-480 V, 64 A, 54 KVA 8AC121.60-1 You are bidding on a B&R ACOPOS 1640 8V1640.00-2 SERVO DRIVE 3x 400-480 V, 64 A, 54 KVA 8AC121.60-1. This item came from a closed auto plant. It is in good shape with just a little damage to the plastic cover. Please see below for specifications. If you have any questions feel free to ask. Below was copied off the web: 8V1640.00-2 Modular mechanical design using plug-in modules Integrated line filter Integrated or optional external braking resistor Integrated electronic restart inhibit Product description: Material number: 8V1640.00-2 Description: ACOPOS servo drive, 3x 400-480 V, 64 A, 32 kW, line filter, integrated braking resistor, DC bus power supply and electronic secure restart inhibit B&R ID code0x12C9 Slots for plug-in modules4 CertificationCEYes cULusYes KCYes FSCYes Power mains connection Permissible power mains formsTT, TN Mains input voltage3x 400 VAC to 480 VAC ±10% Frequency50 / 60 Hz ±4% Installed loadMax. 54 kVA Starting current at 400 VAC26 A Switch-on interval>10 s Integrated line filter in accordance with EN 61800-3, Category C3Yes Power loss at max. device power without braking resistorApprox. 1600 W DC bus connection DC bus capacitance3300 µF 24 VDC supply Input voltage24 VDC +25% / -20% Input capacitance32,800 µF Current consumption at 24 VDCMains input voltage applied- Mains input voltage not appliedMax. 4.6 A + 1.4 * (Current for motor holding brake + Current on 24 VDC output) DC bus power supplySwitch-on voltage455 VDC 24 VDC output Output voltageMains input voltage applied22 to 24 VDC Mains input voltage not applied16.7 to 30 VDC Output currentMax. 0.5 A Motor connection Quantity1 Continuous current64 Aeff Reduction of continuous current depending on the ambient temperatureMains input voltage: 400 VACSwitching frequency 5 kHzNo reduction Switching frequency 10 kHzNo reduction Switching frequency 20 kHz0.96 Aeff per °C (starting at 25°C) Mains input voltage: 480 VACSwitching frequency 5 kHzNo reduction Switching frequency 10 kHz0.96 Aeff per °C (starting at 50°C) Switching frequency 20 kHz0.96 Aeff per °C (starting at 10°C) Reduction of continuous current depending on the installation elevationStarting at 500 m above sea level6.4 Aeff per 1000 m Peak current200 Aeff Nominal switching frequency10 kHz Possible switching frequencies5 / 10 / 20 kHz Electrical stress of the connected motor in accordance with IEC TS 60034-25Limit value curve A Max. motor line length25 m Protective measuresOverload protectionYes Short circuit and ground fault protectionYes Max. output frequency598 Hz Motor holding brake connection Response threshold for open line monitoringApprox. 210 mA Max. output current3 A Max. number of switching cyclesApprox. 80000 Braking resistors Peak power int. / ext.7 / 250 kW Continuous power int. / ext.0.2 / 24 kW Minimum braking resistance (ext.)2.5 ? Rated current of the built-in fuse30 A (fast-acting) Limit switch and reference inputs Quantity3 WiringSink Electrical isolationInput - ACOPOSYes Input - InputNo Input voltageNominal24 VDC Maximum30 VDC Switching thresholdLow<5 V High>15 V Input current at nominal voltageApprox. 4 mA Switching delayMax. 2.0 ms Modulation compared to ground potentialMax. ±38 V Enable inputs Quantity1 WiringSink Electrical isolationInput - ACOPOSYes Input voltageNominal24 VDC Maximum30 VDC Input current at nominal voltageApprox. 30 mA Switching thresholdLow<5 V High>15 V Switching delayEnable 0 -> 1, ready for PWMMax. 100 µs Enable 1 -> 0, PWM offMax. 2.0 ms Modulation compared to ground potentialMax. ±38 V OSSD signal connectionsNot permitted Trigger inputs Quantity2 WiringSink Electrical isolationInput - ACOPOSYes Input - InputNo Input voltageNominal24 VDC Maximum30 VDC Switching thresholdLow<5 V High>15 V Input current at nominal voltageApprox. 10 mA Switching delayRising edge52 µs ±0.5 µs (digitally filtered) Falling edge53 µs ±0.5 µs (digitally filtered) Modulation compared to ground potentialMax. ±38 V Electrical characteristics Discharge capacitance5.4 µF Operating conditions Permitted mounting orientationsHanging verticallyYes Lying horizontallyYes Standing horizontallyNo Installation at elevations above sea levelNominal0 to 500 m Maximum2000 m Degree of pollution in accordance with EN 60664-12 (non-conductive pollution) Overvoltage category in accordance with IEC 60364-4-443:1999II EN 60529 protectionIP20 Environmental conditions TemperatureOperationNominal5 to 40°C Maximum55°C Storage-25 to 55°C Transport-25 to 70°C Relative humidityOperation5 to 85% Storage5 to 95% TransportMax. 95% at 40°C Mechanical characteristics DimensionsWidth276 mm Height460 mm Depth295 mm Weight24.1 kg SHIPPING: Location B2 This item has a shipping weight of 64 pounds and will be shipped by FEDEX or USPS. There is no charge for pick up at our Northwest Detroit Suburb location. You are welcome to physically inspect this item. We are located in a Northwest Suburb of Detroit Michigan. Make an appointment. Specequip at spectorequipment.com 248-752-5084 We accept most forms of payment including: Credit Cards, Pay-Pal, personal, company and cashier’s checks, pay on pick up. All funds must clear our bank before delivery.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	B&R Automation
Country/Region of Manufacture	Austria
Model	8V1640.00-2 8AC121.60-1 8AC120.60-1 acopos 1640
