Click For More Access Control Auto Box Type Set Flap Barrier Single Mechanism Technical Specification : Description Parameter Mechanism 2 X Mechanism Housing 304# Stainless Steel at 1.5mm Size: 1200mm(L)x300mm(W)x1000mm(H) Stardard Width of Passage/Wing Length 600MM/280MM(standard) Power Supply Input AC110/220V±10% Working Voltage 24V DC Power Consumption During Idle 10W/Mechanism Power Consumption During Operation 180W/Mechanism Drive Motor Brush DC Motor 180W/24V Motor Speed 1600 turn/minute Starting Time after Power on 0.5 second Opening/Closing Time 0.8(adjust) Automatic Reset Time after Fault 10 second Pass Speed 40 persons/min(open often), 25-30 persons/min(close often) Protection Level: IP45 Working Temperature: -30°C~50°C Electro-magnetic drive: 24V DC Polishing: Brushed surface (Standard) / Polishing surface Weight: About 120KG/Set Mechanical life: Two million Relative Humidity (RH): 5%-90%(without concretion) Interface: RS485 Control I/O: ±12V electrical level signal or DC12V pulse signal of pulse width >= 100ms Features: ? Reliable and durable, low noise and stable operation, adapt to varied situation,; ? Standard electrical interface, various card reader acceptal to our wing gate & can be (remote) controlled by computer, single/Double Directional Optional which can be controlled by both ways or single way( can be mechanically set by the buttons on built-in control panel) ; ? Gate open automatically when power off to the request of fire protection, and automatically closes when power on; ? The wing gate installed Infrared sensor interfaces, could be expanded to Infrared testing function. ? Breakdown Self-checking and alarm indication, easy for maintenance and using; ? The wing gate arm will automatically locked until opening signal is received, motor will stop working in case of the wing encounter of obstruct;; ? Anti illegal entering alarm: Light and sound alarm is generated when the illegal invasion and the tail followed; ? Automatically reset function: It will automatically lock if the pedestrian hasn't pass through the channel in the pre-set time after the opening. The passing time is adjustable; ? Passage in both directions electronically controlled. The pedestrian retractable barrier is available in Normally Open (N/O) or normally Closed (N/C) mode. In N/O the speed gate provides an always open walkway in rest position and will only close at unauthorized entry or tailgating attempts; ? Driving Mechanism:The wings are moved by mechanical arms. The arms are rotated by a torque shaft connected to the drive unit. The drive unit is a DC motor working in conjunction with a bi-directional encoder. A microprocessor control system guarantees the precise movement and positioning of the wings; ? Method of Operation: ON receiving a signal from the access control system, or push button, the wings open. If an unauthorized person tries to tailgate or attempts to enter from the opposite direction, the system detects the unauthorized passage and activates the in-built alarm system; ? Status Lights: 90mm dia. LED display status lights flush mounted within the speed gates lid top face. Upon authorization a Green arrow will illuminate in the direction of passage authorization whilst in the opposite direction a Red Cross symbol will illuminate to indicate the unit is not available for use or is already in use. Applications: ? Flap Barrier Wing Turnstile is designed to control pedestrian entering or exiting restricted areas, personal surveillance is recommended as the barrier can be breached. The ultra quiet retractable barriers allow for rapid pedestrian movement through the lane while the advanced optical sensors prevent "tailgating" and crawling by those without proper credentials. ?The barrier is available with two wing types, that are either a composition of a 20mm acrylic glass. With the use of soft wings the risk of injury or damage is minimized, even in the event of a visitor running into the closed retractable barrier. Furthermore, a significant increase of the opening and closing time can be achieved, resulting in a much better tail-gating behavior to reach to the customer's advantage. ? Flap Barrier Wing Turnstile is suitable for both indoor and outdoor(tent). It could be wildly used in the place where intelligentized management is needed such as station, port, subway, factory, mansion, intelligent community, hotel, club, marketplace, enterprise and institution etc. Turnstile accessories: ? 2 X Standard Flap Barrier Wing Turnstile Mechanism movement( Single movement) ? 2 X Housing(304#stainless steel at 1.5mm) ? 2 X Standard Flap Barrier Wing Turnstile Control Board ? 2 X Power Supply DC24V/3A ? 2 X Backup storage battery(Wing open when power off) ? 2 X Turnstile Traffic Indicator(standard assorted) ? 2 X Turnstile Passage Status Lights ? 2X Correlation Infrared(standard assorted 3 pairs) Visit Our Store And See Other Items! Add to Favorite Sellers!! Payment: 1.We accept payment via PayPal or HSBC 2,Payment must be received within 7 business days of auction closing. 3.All major credit cards are accepted through our secure payment processor PayPal. Shipping : 1.The product will be shipped via Express logistics(default), the period is about 3 - 6 working days. 2.If you order more items, or the package of Vertical Tripod Turnstiles is more than 1 cubic meters , then it should be shipped by sea freight, customer who want to buy please contact us to check exact the cost of sea freight(we need your specified sea port), 3. we put this advertisement specially for integrator or installer, if you have large amount demand, we could offer better price for bulk purchase. Notice: the delivery period of sea freight normally takes 30-40 days. Top Warranty& Policies: 1.Any durty fee will be paid by the buyers. 2. We have warranty of 1 year after installation, after 1 year, we could provide spare parts at basic cost, according to our experience, the earliest hardware system operated on market has been running for about 8 years and still works very well, so we are confident to sell this system. 3.Due to it is international shipment and will be expensive to return the goods to our factory(even the fault rate is very low), you need to provide Videos, pictures and report if you found the turnstiles is defective(such as a scratch or a dent but still can work) or not working at all, we would also take videos, pictures as proof before delivery, in case any man made mistake during installation, we need to discuss certain percentage compensation or full refund(if it is our fault), or replace some new spare parts(buyer pay for the shipping cost, because you don't need to pay returning cost any more). Contact us : 1.welcome to wholesale and purchase,If you have any question ,Please contact us via eBay message 2.We will reply you within 24 hours.(except weekends and holidays). Visit Our Store And See Other Items! Add to Favorite Sellers!! Top Copyright Hkesuppier 2008. All rights reserved. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
