Assembled Arduino IDE DIY Geiger Kit ver. 1.01 with EEPROM and UART logging RH-K-GK-1-A Soldered kit with high voltage calibrated for SBM-20 and free piezo buzzer! We supply link to download all source files from RH Electronics website. You get carefully packaged high quality product with pre-programmed microcontroller. This is open source code Geiger project based on Arduino IDE. We send all source files links to a buyer. Easy to modify the software. The kit includes main board with 16x2 LCD. 400V high voltage for GM Tube produced with PWM. The kit support external buzzer connection to produce clicker sound similar to a “classic” Geiger counter sound. The kit support eeprom logging of absorbed dose and UART logging of CPM data. Like our other geiger kits, this model can be used for computer monitoring nuclear radiation station with "Radiation Logger" for Windows. The project is education DIY Geiger kit, mostly intended to measure ambient background radiation or low/moderate radiation levels up to 100uSv/h. Note: Geiger Tube, Enclosure, and TTL Module are not included in the purchase! This kit requires TTL module for logging or modifying firmware and ability to use Arduino IDE. Technical specifications: Geiger Tube Compatibility: GM Tubes with anode voltage 350-500V (by default calibrated for 400V tubes) Arduino IDE compatible, easy to modify the program LCD 16x2 HD44780 (fixed properly over main board, no need to use wires) Two tact buttons for controlling the software Moving Average calculating algorithm for CPM Represent dose in uSv/h or uRn/h units UART logging with "Radiation Logger", require USB-TTL dongle EEPROM Logging of absorbed dose Smart Backlight Control Fast Bargraph on LCD Battery Indicator for Ni-MH Supply Voltage: 5V DC or Battery Supply Current: 20mA without backlight Free Atmega Pins for your own needs Compatible with RH-H-GK-1-L SD Logger board Dimensions: 81(L) x 37(W) x 30(H) mm Shipping Weight: 200gr SKU: RH-K-GK-1-A Based on Atmega-328 and programmed with Arduino IDE. In compare to other Arduino based Geiger counters on the market, this product has reduced components amount that makes this project very easy to solder. Atmega microcontroller comes ready to use with bootloader pre-programmed through IDE. You can modify Arduino sketch program if you want. The software and hardware where designed to produce tube high voltage with PWM technology. No additional IC's required, everything is controlled with software. By default it programmed for SBM-20 to 450V-480V. The kit compatible with many popular Geiger tubes, such as SBM-20, SBM-19, SI-29BG, SI-180G, SBT-9, SBT-11, J305 and more 400V range tubes. Absorbed radiation dose in uSv units logged to EEPROM memory once per hour by default or with pressing button on demand. The counter will accumulate lifetime received dose until it reach 1mSv. After that is will re-zero EEPROM value and will start a new loop. You can zero absorbed value anytime by pressing "up" button at device start up. Current radiation dose in uSv/h or uRn/h units represented on LCD with CPM (counts per minute) readings. You can switch between LCD units with pressing "down" button. CPM value logged through UART to our "Radiation Logger" Windows program. When connected to computer, the kit can be used as nuclear radiation monitoring station for local logs, radmon or xively. Fast bargraph on LCD for search mode represent CPS (count per second) measurement. The scale controlled through arduino sketch. The counter has smart LCD backlight controlling for saving battery. Backlight will light on when CPM value reach presetted alert threshold or if you press any button. Alert B/L pin is combined with LCD backlight and can be connected to additional alert led or drive relay module. You can add Active 5V Buzzer or Passive Piezo buzzer to the project. The kit is able to produce clicker "classic" Geiger Counter sound if external buzzer soldered to A3 pin. If you are arduino software developer you can use free atmega pins for other needs through modifying default supplied sketch. Our sketch holds about 1/3 of Atmega flash size that allows you to add additional functions to the project if you wish. The board hardware is also fully compatible with RH-K-GK-1-L model with SD Logger Shield, so you can upgrade or make your own micro SD Shield later. Arduino sketch download link, all required libraries link and printed electrical circuit supplied to the buyer. DOWNLOAD User Manual PDF Radiation Logger Software (require UART TTL Module) this video demonstrate two models: RH-K-GK-1-A and RH-K-GK-1-L, please consider the sku number you purchase! This listing is for RH-K-GK-1-A Package include: 1x Soldered DIY Kit RH-K-GK-1-A model with uploaded default sketch The links to download source files will be sent to buyer email! The kit’s hardware needs 4.6V-5.4V to operate when it drawn 20mA without LCD backlight. There is several options for powering the kit, please consider the best for you. Battery indicator in software will work only with Ni-MH batteries. 1. 4x AA 1.2V Ni-MH rechargeable batteries, 1800mAh or higher. 2. 2x AA 1.5V Alkaline batteries with 5V step-up module. 3. 3.7V LiPO battery with 5V step-up module, 1000mAh or higher. 4. 5V DC regulated power supply for indoor. To our valued customers, please read purchase terms before you bid or buy! Technical issues and support: If you purchase this item you are agree that you have skills and tools to perform required DIY soldering (or de-soldering) and you know how to connect additional external components or modules. All project components should be installed and soldered in proper polarity with proper connectors. Any hardware/software modifications are not covered with warranty. If you have doubt it always better to ask for technical support before doing something. Please download and read carefully PDF user manual, product purchase terms. Almost all technical issues already described in the manual! If you have any technical issue with the product please contact us asap. Support provided by email or via eBay message. Please read support requirements here http://www.rhelectronics.net/store/support-request Please read carefully product title, description and include list. Any questions are welcome. If you received broken or defective parts please contact us first, because we can resolve this problem in best way. Handling time: 5 business days to process international orders required after receiving cleared payment. This does not include the number of business days the shipping service will take to deliver the item to you. We can upload a tracking number during handing time even before your package was transferred to logistic company for the delivery. Shipping: We dispatch your order during 1-3 business day and will upload a tracking number to eBay for USA buyers only. Take note, international shipping is more complicated and longer than domestic, that's why when you buy internationally it mean you are agree to wait for the package. For Economy International Delivery default stated time is 3-5 weeks. Some countries may take longer because of your country custom regulation rules or postal service. USA usually take 2-4 weeks; Europe 1-4 weeks; Australia 2-4 weeks; Germany 3-4 weeks; Israel 3-7 days; Russian Federation 4-8 weeks; All other countries 3-5 weeks default delivery time. Please contact us if you not received your package during 30 days. During checkout you can select available and preferred shipping method for you country. We offer Economy International Shipping and Priority International Express Delivery. If you cannot wait 30-35 days for the delivery please select faster and more expensive method in advance! We do not accept any claims for shipping time if you have chosen Economy Shipping! Economy Shipping mean we'll send your items with Registered Air Mail, but we cannot promise it will be fast, because it depends on post service, flights schedules, weather accidents, custom processing and other things that out of our control. Priority Express Delivery promise you'll receive the order much more faster, so make your decision about shipping method before you pay. Priority Mail available for USA, United Kingdom, Canada, Germany, Australia. Other countries can select EMS Express. Tracking: Take note, we ship through state export account and not from post office branch. This is the reason why your package is trackable only after it was sent abroad from Israel export and not at the date of collecting or at the date we uploaded a tracking number. Online tracking system in Israel displays information with big delays, post website provide tracking info for reference only several days after your item was sent abroad! Please be patient for the delivery and contact us if you have additional questions about shipping. Don't buy/bid if you are not ready to wait for the package during 3-5 weeks when you select Economy Shipping! Don't buy/bid if you make low DSR feedback because of shipping time or shipping price or just because of your custom import tax! Custom & Duty Fee: All international buyers are responsible to cover any possible custom fee or import tax that maybe applied at his/her country. We are obligated by export law of Israel to declare an order price as it was stated in your PayPal bill. German buyers, please remember when you buy that in Germany import custom rules require you to pay fee. We are not accept any claim because of your country custom regulation rules / delays / fee! Please contact your local custom office for more details about custom process and import tax. Returns: Accepted if you not started to solder/use device. In original package, including all components. During 14 days after you receive the package. Payment: Paypal only, or cash for local pickup. V.A.T. : If you live in Israel please take note, all buyers with DELIVERY ADDRESS WITHIN ISRAEL HAVE TO PAY 18% VAT! You'll be charged by separate paypal invoice. Refusing to pay tax will force us to cancel the order. Thank you for your positive feedback!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RH Electronics
Type	Dosimeters
Model	RH-K-GK-1-A
Country/Region of Manufacture	Israel
MPN	RH-K-GK-1-A
