Anritsu Ms2724b Spectrum Analyzer Freq 9khz-20ghz With Psn50 Power Sensor Meter

US $7,450.00

Las Vegas, Nevada, United States
Feb 15th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! ANRITSU MS2724B SPECTRUM ANALYZER FREQ RANGE 9KHZ-20GHZ WITH OPTIONS OPTIONS 9/19/31/44/45 AND PSN50 6GHZ POWER SENSOR AND CABLE TESTED AND CALIBRATED WITH 90 DAY WARRANTY CALL PAUL AT 1-702-285-3432 OR EMAIL VIA EBAY The Anritsu MS2724B Spectrum Master hand-held Spectrum Analyzer is designed to conduct highly accurate analysis on the new wave of wireless LAN and cellular signals, including 802.11a, 3G, ultra-wideband, and wireless medical patient monitoring systems. The next generation of Anritsu's best selling Spectrum Master, the MS2724B is a small and easy to use portable spectrum analyzer with unprecedented measurement capability for applications up to 20 GHz. Weighing in at less than 8 pounds, it is equally at home on the engineering bench and in the field. It is ideally suited for measuring up to the fifth harmonic of 3G cellular phone base stations. An option adds spectrogram, signal strength and RSSI. There is an option to add a user definable channel scanner option that is excellent for interference mitigation work in complicated RF environments. Options are available to add W-CDMA/HSDPA, CDMA, EVDO, GSM/GPRS/EDGE, TD-SCDMA, Fixed WiMAX and Mobile WiMAX measurements. Quasi-peak detection is included along with CISPR resolution bandwidths. Several smart measurements are built into the MS2724B, including channel power, adjacent channel power ratio, Carrier to Interference ratio (C/I), and field strength. In addition, an AM/FM/SSB demodulator is included. Demodulated signals can be monitored using the internal speaker or by using a universal 2.5 mm 3-wire headset, such as used with many cellular phones. The Anritsu MS2724B spectrum analyzer has low phase noise of -104 dBc/Hz typical at 1 GHz @ 10 kHz offset, best in its class typical DANL of -159 dBm at 1 GHz in a 1 Hz RBW, resolution bandwidth (RBW) range of 1 Hz to 3 MHz and video bandwidth (VBW) range of 1 Hz to 3 MHz. It also has the fastest sweep speeds of any spectrum analyzer in its class The use of Compact Flash memory modules or USB Flash Drives allow an unlimited number of traces and setups to be stored. Measurements may be stored directly to the compact flash module. A 512 MB module will hold over 20,000 Spectrum Analyzer measurements. Remote programming using the Ethernet 10/100 Base-T connection is provided using SCPI programming. The Ethernet connection gives the user flexibility in remotely operating the instrument using Anritsu's remote access software, shipped with the product. Measurements and setups may be uploaded and downloaded using either the Ethernet or the USB connection. Quasi-peak detection is included along with CISPR resolution bandwidth. Features of the MS2724B Spectrum Master include: Handheld, battery-operated design Large daylight viewable transflective color display\ Built in pre-amplifier (standard) up to 4 GHz Lightweight at only 7.5 pounds (typical) Best in class Displayed Average Noise Level < -159 dBm typical in a 1 Hz resolution bandwidth at 1 GHz Quick Zoom-in, Zoom-out display in 1-2-5 sequence RBWs: 1 Hz to 3 MHz in 1-3 sequence VBWs: 1 Hz to 3 MHz in 1-3 sequence Automatic or manual input attenuator control Dedicated smart measurements Trace Averaging Normal, Max hold, Min hold, user settable averaging (more than 65,000 traces can be averaged!) Reference Level Offset Three traces Multilingual User Interface (English, Chinese, French, German, Japanese, Spanish, Korean, Italian) Capability to create two custom languages using Master Software Tools and download the languages into the MS2724B Store over 1000 test set-ups internally Save over 1000 measurement traces internally Save directly to compact flash memory Alphanumeric labeling of saved measurements Automatic time and date stamp of saved data Rechargeable/field-replaceable Li-Ion battery 6 Markers plus 6 delta markers or choose one marker with 6 delta markers Multi-segmented upper and lower limit lines 50-ohm Interface standard (75-ohm interface capability - instrument internally corrects for adapter loss) RJ45 Ethernet 10/100 Base T and USB 2.0 Interfaces AM, FM and SSB demodulation with built-in speaker and headset jack. Notes / Included Options 009 - 10 MHz BW I/Q Demodulation Hardware 019 - High Accuracy Power Meter 031 - GPS Receiver (includes GPS Antenna Part Number 2000-1410) 044 - W-CDMA/HSDPA RF Measurements 045 - W-CDMA Demodulation 760-243-R - Hard Transit Case PSN50 - Power Sensor, 50 MHz - 6 GHz, -30dBm to +20dBm, Type N

“90 DAY WARRANTY”

Brand	Anritsu
MPN	MS2724B
Model	MS2724B
Country/Region of Manufacture	United States
