Anritsu Ms2724b Spectrum Analyzer, 100 Khz - 20 Ghz

US $870

Vista, California, United States
Jun 14th

Open on mobile:
QR code

Anritsu MS2724B Spectrum Analyzer, 100 kHz - 20 GHz ******CALL (760) 806-6600 TO RENT THIS ITEM****** DESCRIPTION The Anritsu MS2724B Spectrum Master hand-held Spectrum Analyzer is designed to conduct highly accurate analysis on the new wave of wireless LAN and cellular signals, including 802.11a, 3G, ultra-wideband, and wireless medical patient monitoring systems. The next generation of Anritsu's best selling Spectrum Master, the MS2724B is a small and easy to use portable spectrum analyzer with unprecedented measurement capability for applications up to 20 GHz. Weighing in at less than 8 pounds, it is equally at home on the engineering bench and in the field. It is ideally suited for measuring up to the fifth harmonic of 3G cellular phone base stations. An option adds spectrogram, signal strength and RSSI. There is an option to add a user definable channel scanner option that is excellent for interference mitigation work in complicated RF environments. Options are available to add W-CDMA/HSDPA, CDMA, EVDO, GSM/GPRS/EDGE, TD-SCDMA, Fixed WiMAX and Mobile WiMAX measurements. Quasi-peak detection is included along with CISPR resolution bandwidths. Several smart measurements are built into the MS2724B, including channel power, adjacent channel power ratio, Carrier to Interference ratio (C/I), and field strength. In addition, an AM/FM/SSB demodulator is included. Demodulated signals can be monitored using the internal speaker or by using a universal 2.5 mm 3-wire headset, such as used with many cellular phones. The Anritsu MS2724B spectrum analyzer has low phase noise of -104 dBc/Hz typical at 1 GHz @ 10 kHz offset, best in its class typical DANL of -159 dBm at 1 GHz in a 1 Hz RBW, resolution bandwidth (RBW) range of 1 Hz to 3 MHz and video bandwidth (VBW) range of 1 Hz to 3 MHz. It also has the fastest sweep speeds of any spectrum analyzer in its class The use of Compact Flash memory modules or USB Flash Drives allow an unlimited number of traces and setups to be stored. Measurements may be stored directly to the compact flash module. A 512 MB module will hold over 20,000 Spectrum Analyzer measurements. Remote programming using the Ethernet 10/100 Base-T connection is provided using SCPI programming. The Ethernet connection gives the user flexibility in remotely operating the instrument using Anritsu's remote access software, shipped with the product. Measurements and setups may be uploaded and downloaded using either the Ethernet or the USB connection. Quasi-peak detection is included along with CISPR resolution bandwidth. Features of the MS2724B Spectrum Master include: Handheld, battery-operated design Large daylight viewable transflective color display\ Built in pre-amplifier (standard) up to 4 GHz Lightweight at only 7.5 pounds (typical) Best in class Displayed Average Noise Level < -159 dBm typical in a 1 Hz resolution bandwidth at 1 GHz Quick Zoom-in, Zoom-out display in 1-2-5 sequence RBWs: 1 Hz to 3 MHz in 1-3 sequence VBWs: 1 Hz to 3 MHz in 1-3 sequence Automatic or manual input attenuator control Dedicated smart measurements Trace Averaging Normal, Max hold, Min hold, user settable averaging (more than 65,000 traces can be averaged!) Reference Level Offset Three traces Multilingual User Interface (English, Chinese, French, German, Japanese, Spanish, Korean, Italian) Capability to create two custom languages using Master Software Tools and download the languages into the MS2724B Store over 1000 test set-ups internally Save over 1000 measurement traces internally Save directly to compact flash memory Alphanumeric labeling of saved measurements Automatic time and date stamp of saved data Rechargeable/field-replaceable Li-Ion battery 6 Markers plus 6 delta markers or choose one marker with 6 delta markers Multi-segmented upper and lower limit lines 50-ohm Interface standard (75-ohm interface capability - instrument internally corrects for adapter loss) RJ45 Ethernet 10/100 Base T and USB 2.0 Interfaces AM, FM and SSB demodulation with built-in speaker and headset jack. Notes and Included Options: 009 - 10 MHz BW I/Q Demodulation Hardware 019 - High Accuracy Power Meter 025 - Interference Analyzer 031 - GPS Receiver (includes GPS Antenna Part Number 2000-1410) 035 - Over The Air, WCDMA 044 - W-CDMA/HSDPA RF Measurements 065 - W-CDMA/HSDPA Demodulation 760-243-R - Hard Transit Case PSN50 - Power Sensor, 50 MHz - 6 GHz, -30dBm to +20dBm, Type N *All of our equipment has been tested. Additional calibration may be available upon request! ~This sale includes all items shown. No unseen parts or accessories will be included~ PAYMENT AND SHIPPING INFO Warranty Info & Return Policy We strive to exceed our customer's expectations and maintain 100% Positive Feedback. Although we do not use eBay's automated Return Policy, all goods or equipment sold by AxiomTest include a 30-Day Warranty which starts the day the equipment is shipped. So contact us immediately if there is a discrepancy with your order or an equipment malfunction so we can issue a repair, replacement, or refund. Returns must be shipped with all original packaging and accessories. We will not accept any items with obvious signs of additional wear and tear or internal component alterations. All of our items will ship with “Warranty Void” tamper resistant stickers. If any stickers have been removed or tampered with your refund will be canceled. Please include your RMA # on the packing slip, way bill, or package. *CUSTOMER RESPONSIBLE FOR ANY AND ALL RETURN SHIPPING COSTS Payment Options Domestic Buyers - PayPal, Wire Transfer, Money Order, Company, Bank, or Personal Check. International Buyers: PayPal or Wire transfer only. All funds must be in US Dollars. Unsecured funds must clear prior to shipment. Wire Transfers subject to a $25 service fee. Shipping Unless noted otherwise, all shipments are done through FedEx. If you would like to utilize your own shipping account please notify us PRIOR to checkout. Saturday and Residential delivery may be available at an additional third party charge depending on the shipping method you choose. We offer shipping outside of the United States. However, some international laws prohibit us from shipping certain items to certain countries. Additionally, not all countries are supported by our service provider. You may also elect to use your own carrier, but we'll be responsible for providing the correct documentation and scheduling the pickup. We are not set up to ship via USPS, and we will NOT falsify any import documents for international orders - no exceptions. Please note: In all sales where an item is prohibited to ship internationally to a successful buyer, that buyer will be notified of non-shipment and a full refund will be made. We reserve the right not to ship any item internationally that is controlled by the US Department of Commerce’s laws and regulations and deemed non-shippable to that region of the world or to listed individuals. eBay's International Shipping calculations do not include any additional duties, fees, or VAT that may be associated with importing this item into a foreign country - please bid accordingly Sales Tax California residents will be charged sales tax if no resale or tax exempt form is submitted prior to payment. TRIED, TESTED...ACCEPTED.
