Agilent U2001a 10 Mhz - 6 Ghz Usb Power Sensor (opt. 100) Tested!!

US $1,200.00

  • Boise, Idaho, United States
  • Mar 2nd
You are bidding on  U2001A USB Power Sensor Used but in EXCELLENT WORKING condition w/ USB Cable Signal Generator HP 8648B is NOT included!  The Agilent U2001A is a standalone RF Power Sensor that operates like a power meter. It's fast measurement speed helps reduce test time. This, coupled with the capability to enable monitoring of more than 20 channels simultaneously, is an advantage in the production line where efficiency is of utmost priority. The U2001A has both internal and external zeroing capabilities. With internal zeroing, high isolation switches in the sensor are opened to isolate the sensor from the device-under- test (DUT) it is connected to. The U2001A USB power sensor is a true-average, wide-dynamic-range RF/microwave power sensors, based on a dual-sensor diode pair/ attenuator/diode pair topology. Specifications. Frequency range: 10 MHz to 6 GHz. Power range: -60 to +20 dBm. Maximum power: +25 dBm avg 20 VDC, +33 dBm pk < 10 µs. Maximum SWR: 1.15 (10 to 30 MHz), 1.13 (30 MHz to 2 GHz), 1.19 (2 to 6 GHz). Measurement speed Normal: 20 readings/s. Measurement speed Fast: 110 readings/s. Average only mode (default mode): optimized for wide dynamic range. In this measurement mode, a trigger can be controlled externally via TTL input. Normal^2 mode: used for making average power measurement in a defined time interval (time-gated measurement) with reduced dynamic range. A trigger can be derived from an RF signal (internal trigger) or controlled externally via TTL input (external trigger). Accuracy (25 °C ± 10 °C): ±3.0% (60 to +20 dBm). Current requirement: 200 mA max (approximately). Connector type: N-type male, 50 ohm.
In Excellent Working condition see photos. (SN. MY51200016 )Signal Generator NOT included!HP 8648B Signal Generator displayed to DEMONSTRATE that this item is in working condition and is NOT included with this sale.
Brand Agilent
MPN U2001A Opt100
Model U2001A Opt100
