Agilent / Hp 83594a Sweeper Plug-in, 10 Mhz-26.5 Ghz, Refurbished

US $1,750.00

Melrose, Massachusetts, United States
Jun 9th

Open on mobile:
QR code

Agilent / HP 83594A Sweeper Plug-In, 10 MHz-26.5 GHz Refurbished - TESTED Calibrated output power with 0.1 dB resolution +13 dBm from 0.01 to 18.6 GHz 12 MHz frequency accuracy at 26.5 GHz -55 dBc harmonics and subharmonics from 3.5 to 20 GHz Internal leveling and slope standard HP-IB Six HP 83590 series plug-ins feature wideband frequency coverage as exemplified by the HP 83595A which covers 0.01-26.5 GHz in a single sweep. While the HP 83590 series feature broadband sweeps, they still maintain narrowband precision. The frequency output exhibits excellent stability and accuracy. At 26.5 GHz the HP 83595A maintains an accuracy of ± 12 MHz. The HP 83592B does not sacrifice power for broadband high frequency coverage; the output power is internally leveled for a minimum +13 dBm (to 18.6 GHz) output with ± 0.9 dB flatness. The HP 83592C provides a clean test signal with -55 dBc harmonic and subharmonic levels (3.5-20 GHz) to maximize dynamic range. Power output capabilities have been expanded to provide power sweep and slope control. In addition, the HP 83590 series plug-ins are completely HP-IB programmable. The most outstanding feature of the HP 83590 series plug-ins is their broad frequency range. Innovative technology is used to create this precision frequency range. The principle behind this technology is the Switched YIG Tuned Multiplier circuit (SYTM). The YTM circuit uses the output of a fundamental oscillator to drive a high-efficiency multiplier that has been integrated with a tracking YIG filter in order to create and select high order harmonics to be used as output frequencies. A figure of merit for the HP 83590 series is their flat output power over the entire frequency range. The output power is internally leveled within 0.9 dB with a displayed resolution of 0.1 dB. The power level may be controlled to a minimum settable power level of -5 dBm (-2 dBm for the HP 83592B). This level may be extended to -75 dBm on the HP 83592A and HP 83590A or to -72 dBm on the HP 83592B with Option 002 (70 dB Step Attenuator), or to -60 dBm on the HP 83592C, the HP 83595A and HP 83594A with Option 002 (55 dB Step Attenuator). Since power parameters are critical to high frequency measurements, the HP 83590 Series (along with all HP 83500 series plug-ins) offer many modes of power output. In addition to a single power output, the HP 83590 Series offer a Power Sweep function. The Power Sweep function sweeps a power range for characterizing level sensitive devices like amplifiers and transistors. The Slope mode is supplied to provide compensation for cable or test set losses. In all these modes the power output is internally monitored and leveled. If preferred, the power may be externally leveled. The HP 83590 Series plug-ins are capable of power meter leveling with the HP 432A/B/C, 436A, and 438A power meters. HP-IB programmability is an essential feature when one of the HP 83590 series is used in automatic test systems. For example, the automated tests of amplifiers for gain compression are possible. These plug-ins are completely programmable, which means the power mode may be selected and the power level may be set with .01 dB resolution. PO Boxes/APOs require USPS shipping, may experience longer lead times. 6.25% Sales Tax for shipping to Massachusetts Terms and Conditions Have a Question? Send us a message (Contact Seller). We are shipping from just north of Boston, MA in the United States. For international customers, do not assume a product will work in your country due to various International Voltage requirements. Ask first if you are not sure. Warranty (Refurbished Items/Open Box/Surplus): 5 day Right of Return. If the item is found to be defective, contact us to be issued an RMA. Warranty Returns do not apply to listings that indicate: requires parts, needs repair, or as-is in the title and/or description. In case of returns, buyer is responsible for all shipping fees. (Domestic or International) International Shipping Terms: * International customers are responsible for all shipping charges, including any duties or taxes that may be enforced by their respective country. *International shipping charges paid do not include destination country importation fees including Custom Fees, Broker Fees, Duties and Taxes * USPS is the most economical shipping method for international customers. With this often comes a slightly delayed lead-time or erratic tracking information. We ask for your patience, and we will do the best we can to see you get your shipment quickly and accurately. Feedback: We appreciate your Positive feedback. We leave feedback for buyers as soon as our transactions complete. If you have any problems with the sale, we will do anything within reason to correct or improve your experience. If negative feedback is left prior to an attempted resolution, we reserve the right to accept that as the final resolution. We will not accept a return or issue a refund. *Note Estimated Delivery time above. Please contact us if you require specific details, or have a required delivery date. Please contact us for shipping rates to any overseas US

“Used, Tested by our Technician, Ready to Go!”

Brand	Agilent / HP
MPN	83594A
