Agilent E4406a Vector Signal Analyzer Series Transmitter; Options 202, Baf,uk6

US $1,575.00

Bedford, Virginia, United States
Jan 29th

Open on mobile:
QR code

Now available for Sale with FREE US Shipping--Very Good Condition. Removed from test labs of world class manufacturing operation. Agilent Technologies E4406A Vector Signal Analyzer Series Transmitter Tester 7 Mhz- 4.0Ghz. Includes Options: 202, BAF, UK6. Power: 100-115v/ 230-240v, 50-60/ 400hz. Description The E4406A VSA transmitter tester is a full-featured vector signal analyzer ideally suited for base station and mobile handset manufacturing, with additional applications for design and development of wireless equipment. The E4406A VSA offers high performance in-band and spectrum measurements for multiple 2G, 2.5G, 3G, and 3.5G wireless communications formats with powerful one-button standard-based measurements, and the best combination of speed and accuracy. Its speed and affordable price make it well suited for volume production. Extensive one-button measurement personalities, superior accuracy and optional baseband IQ input provide unparalleled convenience for research and development applications. Features Multiple domain analysis for frequency domain, time domain and code domain One-button standard-based measurement personalities (W-CDMA, HSDPA, cdma2000, 1xEV-DV, cdmaOne, 1xEV-DO, GSM, EDGE, NADC, PDC and iDEN) Pass/fail test capability with built-in test limits for manufacturing application Up to three times faster measurement speed than a typical spectrum analyzer Baseband IQ input option (5 Hz to 10 MHz, balanced and unbalanced) to analyze the complete signal path of components and devices (receiver or transmitter). Go to the Baseband IQ input option. Link to 89601A vector signal analysis software, enabling users to control and directly extract data from the E4406A for flexible demodulation analysis on a PC Specifications Frequency range: 7 MHz to 4 GHz (RF input) and 5 Hz to 10 MHz Absolute amplitude accuracy at 1 GHz: ?0.6 dB Displayed average noise level at 1GHz: -136 dBc/Hz Dynamic range (3rd order) at 1 GHz: 102 dB (B7C baseband I/Q input: 50 Ohm unbalanced, 600 Ohm & 1MOhm balanced) OPTIONS BAF W-CDMA Measurement Personality 202 EDGE Measurement Software This unit provides the ability to design and develop both base band and RF components and test them together. The base band IQ inputs option supports digital demodulation measurements for the EDGE, cdma 2000, W-CDMA and basic measurement personalities on it. This option also supports both unbalanced 50? and 1M ?, and balanced 600? and 1M ? inputs. Each I and Q input has a frequency range of 5Hz to 5MHz, giving a combined composite bandwidth of 10MHz. With base band IQ inputs this provides an economical low frequency (5Hz to 5MHz) or 10MHz I/Q front-end for the 89601A vector signal analysis software Supports baseband EDGE and GSM measurements (transmit power, GMSK PVT, phase and frequency, spectrum, waveform, EDGE EVM and EDGE PVT). Supports baseband W-CDMA measurements (code domain power, modulation accuracy, QPSK EVM, power statistics CCDF, power control, and PVT, channel power, occupied bandwidth, spectrum and waveform). Supports baseband cdma2000 measurements (code domain power, modulation accuracy, QPSK EVM, power statistics CCDF, channel power, occupied bandwidth, spectrum and waveform). Supports basic mode measurements (spectrum, waveform, power statistics, CCDF, and channel power). Supports 89601A vector signal analysis software. Additional Specifications Frequency range: RF input:7 to 314 MHz and 329 MHz to 4 GHz Baseband IQ inputs: 0 Hz to 5 MHz Frequency spans: 5 Hz to 5 MHz (Baseband I or Q inputs) 10 Hz to 10 MHz (Composite I/Q) Frequency setting resolution: 1 Hz RF input: 20 MHz to 2 GHz

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Very good condition with normal wear. Removed from test labs of world class manufacturing operation.”
