3d Lightsquared Diy Kit 4x4x4 2*5*7mm Led Cube White Led Red/blue Ray New

US $380

  • Shenzhen, China
  • May 28th
We accept PayPal payment ONLY. If you have any issues with the product, please contact us freely. Find more items in our store by clicking here! The Steady 3D LightSquared DIY Kit LED Cube White LED Red/Blue Ray is a 4x4x4 cube that comes with 2*5*7MM LEDs. It's perfect for those who are looking to create a unique and dazzling color effect. The cube runs on a 5V service voltage and measures 71*73mm. The kit includes a PCB board, 70 blue ultra-bright LED long legs, 2 40 p round line motherboards, 5mmLED interval columns, 4 5MM diversified LED lights, 4 15 mm copper columns, a DC005 to USB power supply line, a DC005 seat, a 25 v470uf electrolytic capacitor, 4 1 k resistors, a 40 p chip base, a written procedure for STC12C5A60S2 burn, 3 22 p ceramics capacitors, an 11.0592 M crystal vibration, and a 1m single conductor Empty PCB board. To make the kit, use the layer connection method and the beam connection method. The left side of the top layer (that is, on the 4th floor) of the total cathode layer control line is P2.0, common cathode layer control line on the left side of the second layer is P2.1, common cathode layer, Layer 3 control line on the left is P2.2, the left side of the fourth layer (that is, the bottom) of the total cathode layer control line is P2.3, the right side of the top level (that is, on the 4th floor) of the total cathode layer control line is P2.4, right side common cathode layer layer 3 control line is P2.5, common cathode layer controls the right side of the line of the second layer, is P2.6, the right side of the first layer (that is, the bottom) of the total cathode layer control line is P2.7. Once everything is connected, it can be assembled into a 4 * 4 * 4 cube of light.
