3channel Programmable Dc Power Supply Triple Output 0-30v/3a 2.5v/3.3v/5v/3a Usb

US $250

Shenzhen, China
May 27th

Open on mobile:
QR code

Note: we'll ship this item via express mail service to USA, Canada, Australia, New Zealand, Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxemburg, Malta, Norway, Sweden, Swiss, Spain, Italy, UK, Japan, Korea,Thailand, Malaysia, Indonesia, Philippine, Singapore. Clients from other countries pls contact with us in advance to confirm the different shipping charges before you order. PPS3003T-3S Features: 1. 3 independent outputs: PPS3003T-3S, 30V/3A (PPS3005T-3S, 5A) x2, selectable 2.5V/3.3V/5V/3A x1(fixed) 2. Min. resolution: 100mV, 10mA 3. Digital panel control (rotary encoder switch, rubber key with indicator) 4. User-friendly operation, coarse/fine control for voltage and current. 5. 4 sets of panel setup save/recall 6. Output ON/OFF, key-lock, warning buzzer 7. Tracking series and parallel mode. 8. Software calibration 9. Smart cooling fan achieving low noise. Specifications: 1. Voltage Output: CH1 & CH2, 0-30Vx2; CH3, 2.5V/3.3V/5Vx1 2. Current Output: PPS3003T-3S, CH1 & CH2, 0-3Ax2; CH3, 3Ax1 (fixed); PPS3005T-5S, CH1 & CH2, 0-5Ax2; CH3, 5Ax1 (fixed) 3. Constant Voltage Operation: line regulation: =<0.01%+3mV; Load regulation: =<0.01%+3mV (I=<3A); =<0.02%+5mV (I>3A) Ripple and noise: =<1.0mVrms (I=<3A)(5Hz-1MHz); =<2.0mVrms(I>3A)(5Hz-1MHz) Recovery time: =<100uS ( 50% load change, min. load 0.5A) Temp-coefficient: =<300ppm/C Output range: 0 to rating voltage continually adjustable 4. Constant Current Operation: line regulation: =<0.2%+3mA; Load regulation: =<0.2%+3mA (I=<3A); =<0.2%+5mA (I>3A) Ripple current: =<3mArms (I=<3A); =<6mArms (I>3A) Output range: 0 to rating current continually adjustable 5. Tracking Operation: Regulation of PAR, line regulation: =<0.01%+3mV; Load regulation: =<0.01%+5mV (I=<3A); =<0.02%+10mV (I>3A) Regulation of SER.: line regulation: =<0.01%+5mV; Load regulation: =<300mV Tracking error: =<0.5%+100mV if master (no load, with load added=<300mV) 6. Display: Voltage full scale: 32.0V, 3 digits, 0.5-inch LED display; Current full scale: 3.20A, 3 digits, 0.5-inch LED display 7. Resolution: Voltage: 100mV; Current: 10mA 8. Program accuracy (25+-5C): +-(0.5% of RDG + 2 digits) (0-30V); +-(0.5% of RDG + 2 digits) (0-3A); +-(0.5% of RDG + 5 digits) (>3A) 9. Readback accuracy (25+-5C): +-(0.5% of RDG + 2 digits) (0-30V); +-(0.5% of RDG + 3 digits) (0-3A); +-(0.5% of RDG + 5 digits) (>3A) 10. CH3 specifications: Output voltage: 2.5V/3.3V/5V +-8%; Output current: 3A; Regulation (25+-5C): Line regulation: =<25mV; Load regulation: =<25mV. Ripple and noise: =<2mVrms 11. Key lock function. 12. USB interface. 13. Memory save/Recall. 4 sets of panel setup and 1 set of the memory status before closed. 14. Power source: 110-127V AC+-10%, 220-240V AC+-10%, 50-60HZ +-2Hz 15. Size: 310mm x 250mm x 150mm 16. Weight: PPS3003T-3S, 7.5Kg; PPS3005T-3S, 10Kg. Accessories: USB cable, CD software, power cord(US, Euro, UK and AU plug is available).
