3 In 1 Din Rail Current Voltage Power Ammeter Voltmeter Display Meter

C $42.19

  • Hong Kong, Hong Kong
  • Jan 29th
Payment Shipping Terms Return Policy Feedback Contact us Din Rail Current Voltage Power Ammeter Voltmeter Display Meter Description Can measure current, voltage, power. Buy instantly! 1 Accuracy: 1% plus or minus two bytes 2 Display: voltage, current, power display 3 Measurement range: AC Voltage: AC 80-300V 4 AC current: AC 0-100.0A, when measuring current is less than 10A, current display resolution is 0.01A; when the current is more than 10A, current resolution is 0.1A, measuring range automatically convert (decimal point automatically shift) 5 Active power: ( measuring voltage AC 80-300V) 5-30000W, normally display starts with 3W measuring power! 6 Apparent power: ( measuring voltage AC 80-300V) 5-30000W, normally display starts with 3W measuring power! Power Factor: 1.000-0.000 7 Measurement speed: about 2 times per second 8 Dimensions: 54 (L) x 80 (W / H) x 64 (D) mm 9 Installation width: = 3P (DZ47 / C45, air switch position) 10 Meter protruding part size: 54 (L) x 45 x (W / H) x 16 (D) mm 11 Installation way: din-rail (market universal din-rail) Note: din-rail not included  12 Built-in mutual inductor: the wire to measure circuit through the right round hole of the meter (11MM round hole diameter can pass through max. 12 square (mm) standard copper wire / can meet max. load current 100A) Note: The load is through the meter round hole from above or below, do not affect the current measurement accuracy. 13 External mutual inductor (hole diameter 15.5mm) can meet national standard 21-25 square (mm) standard copper wire to pass through. 14 This meter is only suitable for pure AC 50-60HZ electric supply, not for measuring square wave, converter output and modified sine wave circuit, otherwise the instrument will be permanently damaged! Usage and wiring methods 1 measured voltage accesses to the terminal 1 and 2 on the lower left of the instrument 2 external mutual inductor wiring according to diagram in FigureI, the two wires of precision current mutual inductor are connected respectively to the 3 and 4 terminal on the upper left side; the wire to measure circuit through the mutual inductor round hole. (mutual inductor lead can be extended to ideal installation place by yourself in accordance with your equipment) extended length of 0.5-3 meters. 3 built-in mutual inductor wiring according to diagram in FigureII,  the wire to measure circuit through the right round hole of the meter, users choose the direction they needed, can pass from bottom round hole upwards, or pass from upper round hole downwards, different directions do not affect measuring result. 4. after connected to power supply, the meter displays the measured values, sequential display of power measurement is: display active power (W) after power on, press the left button on the instrument panel (SAM CK), display apparent power (VA), press the button again to display power factor (cos?) 1 x Ammeter voltmeter power meter 1 x English user manual Packaged in carton Payment Shipping Terms Return policy Feedback and Detailed Seller Ratings Contact us We only accept payment through Paypal. Please make sure you have a valid PayPal account prior bidding. Please pay for your item within 5 days of the auction end time. All items will be shipped to buyer's ebay address. Before you pay, please make sure your address in ebay matches the address you would like us to ship to. All items will be shipped within 48 hours upon receipt of payment. In most cases, international shipping takes around 7-14 business days. We try our best to provide you with the most reliable, affordable way of shipping. But sometimes international delivery is highly dependent on the local customs and post service. If you do not receive your item on time, please contact us immediately for further assistance. We take responsibility for any damages or losses incurred in the shipping process. Listings with shipping and handling charge: the charge covers mailing, packing, warehouse and distribution costs, not only postage. Please Note: Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying. If any item is defective upon receipt, please contact us for the return address, returns are accepted within 14 days after the buyer receives the item. Returned item has to be in its original condition. Buyer is responsible for return shipping costs. After receiving the return we will make a replacement depending on our available stock, if not available, a refund will be issued. Dear buyers, we appreciate your business, if you are satisfied with our service, please leave us positive feedback and rate the details of the transaction (Detailed Seller Ratings) with a "PERFECT 5 STARS". When you rate the shipping time section please take international transit into consideration.Your recognition will make us more confident to develop business and serve you better. Our goal is to make sure you are a happy buyer and have a pleasant shopping experience with us. Please email us before leaving any 1 or 2 ratings, negative feedback or open any dispute. We understand the concerns and frustrations that occasionally occur, and appreciate the opportunity to assist you in resolving any problem associated with your purchases. We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply to your emails as soon as possible, however, due to high volume of daily incoming emails and time zone difference, we may not be able to reply your emails immediately. Please allow 24 business hours for us to respond. About item:For the functional products in our shop (such as: Chargers, Data cables), we make sure that the functions are the same as description, but the actual color and shape may looks a little different from pictures because of the technical improvement and manufacturing variance. Please be advised before you bid.
