3.3v-5v Active 3 Pin 1 Channel Output Angle Sensor Module For Develop Engineer

US $2.99

Shenzhen, ???, China
Jun 9th

Open on mobile:
QR code

3.3V-5V Active 3 Pin 1 Channel Output Angle Sensor Module + 3pcs cable free Arduino Compatible Mini Flame Fire Wavelength Sensor AVR PIC New Potentiometer Sensor module Rotation Angle Sensor Arduino competible Flame Sensor Module for Sensor Shield For Arduino ATmega328 2560 LM393 3v-24v STC89C52 Descriptions: Angular Transducer Tilt Slant Angle Sensor Module 1 Channel 3 Pin 1 Channel Output Angle Sensor Module 3.3V-5V Active 3 Pin 1 Channel Output Angle Sensor Module tilt slant tilt slant angle sensor Applications: angular transducer, tilt slant angle sensor. Angle sensor direction changes, the output low level, triggering singlechip module. The output can be directly connected with the single chip microcomputer, through the single chip microcomputer to detect the high and low level, thus to detect angle change. The output can be directly driven relay module (relay module is not included), which can form a temperature control switch. One: module description 1 The sensor that can sense changes in the angle of the object 2 Operating voltage 3.3V-5V 3 Output form of digital switching output (0 and 1) 4 has a fixed bolt hole for easy installation 5 small plates PCB size: 3cm * 1.6cm Module Interface Description (3-wire) 1 VCC external 3.3V-5V voltage (can be directly connected to the 5v microcontroller and 3.3v microcontroller) 2 GND external GND 3 DO-board digital output interface (0 and 1) Note: AO mouth is invalid for this, do not do any processing. Three: instructions for use A tilt sensor using the MEC original tilt switch SW-460D, high sensitivity, and is generally used to detect changes in the angle of the object. 2 module without inclination or the inclination angle to reach the threshold value is set, DO port outputs a high level, when the sensor when the inclination angle exceeds the threshold value is set, the module D0 output is low; 3 small board digital output D0 and SCM directly connected to the microcontroller to detect high and low, to detect changes in the angle of the object; 4 board digital output DO shop relay module can directly drive, which can form a tilt switch; Four: module application Tire pressure monitoring system (TPMS), bicycle lights, digital photo frame rotation, screen rotate, flip video camera, anti-theft system Five test instructions By using our 51 development board with tilt sensor module test Wiring instructions: The module VCC pick development board VCC The module GND with development board GND The connected VCC and GND, module power indicator will light The module level gently on the desktop, the modules slowly rotate in one direction, the switch indicator lights, and then module rotates in the opposite direction, back to the initial state, switch indicator will destroy. This phenomenon is to explain, can trigger the module to change the sensor angle, so that the switch indicator lights. Addition, information which comes with a 51 program, used to detect the tilt sensor module digital interface D0 high and low Specifically described as follows: Wiring: The module VCC pick development board VCC The module GND with development board GND Module D0 connected development board P0.1 SCM: STC89C52 Serial port to send data baud rate: 9600 Phenomenon: module angle change the trigger the serial constantly sending 01 simultaneous switching light; No angle change does not trigger the module, the serial port is not sending data, the lamp is off. Country Approx. Delivery time United Kingdom /United States / Australia 10-16 working day Canada 12-21 working day RUSSIAN/Brazil / Africa / South America may take up to 20-40day due to strict Custom Inspection Italy / France / Spain / Germany may take up to 12-20 day due to strict Custom Inspection Note: if you want ship via EMS ,DHL ,UPS express ,please contact for additional shipping fee pls donot leave us NEG or NEUTRAL feedback on ebay before contact with us for the problem

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	oem
Country/Region of Manufacture	China
Model	ans01
