2x Fa432 Switch On-off Circulated 1-180 Min,timer Delay Relay Cycling,assembled

US $36.74

Bangkapi, BA, Thailand
Jun 9th

Open on mobile:
QR code

2x FA432 SWITCH ON-OFF CIRCULATED 1-180 MIN,TIMER DELAY RELAY CYCLING, 12VDC 10A 200W CD4060, ASSEMBLED KIT (2 Pcs.) Introductory The FK4XX Series is a rich source of projects for classroom construction and are ideal demonstrations of applied sensors of several types. Most of the FK4XX series embody three of the basic elements of electronic control i.e. Input, Process and Output, in broad range of economical, easy-to-build circuits. An additional benefit of this series is that these proven, functional control units are easily adapted to industrial, security and domestic systems. These units are available also as pre-assemblies under the FA prefix. FK432: CIRCULATED ON-OFF SWITCH 0-180 MIN Detail: • Able to control the on-off function freely from 1 to 180 minutes. • With 200 watt maximum electrical home appliances. • Power supply : 12Vdc. • PCB dimensions : 3.0” x 1.9” (1"=2.54 cm.) 1-180 Minutes Adjustment of each state ( on/off ) 2 Ranges of Time setting # 2 second To 2 minutes in case, of jumper is in "L" position # 2 minutes To 180 minutes in case, jumper is in "H" position Require Power Supply 12VDC Maximum Load 7A / 220VAC Maximum Load 10A / 120VAC Example : Set the Lamp to turn on 10-15 minutes and turn off 30-60 minutes , board works as cycle until power off. The ON and the OFF times of the FK432 recycling timer can be independently set over the ramge 1 to 180 minutes. The timers onces set will each time out to their preset intervals and repeat the cycle. Applications include industrial process control, public display lighting, stairwell lighting and dark-room timing. Technical data - Power supply : 12VDC. - Electric current consumption : 45mA (max.) - Maximum contact : 5A@220VAC - Renge : from ±1 to ±180 minutes - IC board dimension : 3.01 in x 1.87 in How does it work IC1 acts as the ON timer and VR1(ON) incharges of time adjustment from 1 to 180 minutes. TR1 conducts the current to the circuit, LED display and relay works. The collector of TR1 resets IC2 at pin12 to stop IC2. VR1 makes TR1 stop transferring current on setting time, relay will stop working, LED does not display and pin3 of IC2 is not reset. IC2 can be worked by adjusting OFF timer, IC2 will then send OUTPUT to pin3 to reset IC1 so that OUTPUT at pin3 does not have voltage. While TR1 works, LED displays and relay works. At the collector of TR1 has high voltage and reset IC1 respectively making IC2 reset. At pin3 of IC2 is stopping reset IC1 so that IC1 is working and acts as timer as normal condition. Circuit Assembly The assembly of components is shown in Fig. 2. For good looking and easy assembly, the shorter components should be first installed - starting with low resistant components and then the higher. An important thing is that diodes, electrolyte capacitors, and transistors shall be carefully assembled before mounting them onto their right anode/cathode of the IC board otherwise it might cause damage to the components or the circuit. Configuration of the anode and the cathode is shown in Fig 3. Use the soldering iron/gun not exceeding 40 watts and the solder of tin-lead 60:40 with flux within. Recheck the correctness of installation after soldering. In case of wrong position, just use lead absorber or lead extractor wire to avoid probable damage to the IC. Testing When correctly finishing up the installation, turn both potentiometer max. counterclockwise, connecting JP1 and JP2 to "H" position. Supply the power supply 12VDC to the circuit. LED is displaying while relay is working for 1 minute then stopping, and again showing. Potentiometer VR1(ON) incharges for relay and LED working adjustment maximum to 180 minutes while VR2(OFF) incharges for relay and LED non-working adjustment from 1 to 180 minutes. If jumping JP1 and JP2 to "L" position, it can be adjustment timer from 1 second to 1 minute. Free Shipping Handling WORLDWIDE. The package will be shipped directly from Thailand via Economy/Standard Small package Airmail, and it will take about 11-23 Business Days (or about 2-5 Weeks) **Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer’s responsibility. **Please check with your country’s customs office to determine what these additional costs will be prior to bidding / buying Return Policy 100% Satisfaction Guarantee: If you are not satisfied with the product you purchased for any reason, please contact us for a return instruction within 30 days Shipping Handling costs are not refundable. Return shipping cost will be paid by buyer. We accept ONLY PayPal for payment. Contact us Please contact us by eBay message only.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Future Kit
MPN	111014
Model	FA432
Country/Region of Manufacture	Thailand
UPC	Does not apply
