2pcs HC-SR501 Human Sensor Module Pyroelectric sensor Infrared for Arduino Product Description: 1. Electrical parameters Product Type: HC--SR501 Body Sensor Module Operating voltage range: DC 4.5-20V Quiescent Current: <50ua Level output: High 3.3 V /Low 0V Trigger: L can not be repeated trigger/H can be repeated trigger(Default repeated trigger) Delay time: 5-200S(adjustable) the range is (0.xx second to tens of second) Block time: 2.5S(default)Can be made a range(0.xx to tens of seconds Board Dimensions: 32mm*24mm angle Sensor: <100 ? cone angle Operation Temp: -15-+70 degrees Lens size sensor: Diameter:23mm(Default) 2. Features The automatic sensor: to enter the sensor output range is high, people leave the sensor range of the automatic delay off high, output low The photosensitive control (optional, factory is not set) may set the photosensitive control during the day or light intensity without induction The temperature compensation (optional, factory is not set): In the summer when the ambient temperature rises to 30 ~ 32?, slightly shorter detection range, temperature compensation can be used as a performance compensation Two trigger mode: (can be selected by jumpers) a, can not repeat the trigger: the sensor output high, the delay time is over, the output will automatically become low from high; b, repeatable trigger: the sensor output high after the delay period, if the human body in its sensing range activities, its output will remain high until after the delay will be left high to low (sensor module review measured activities of each body will be automatically extended after a delay time, and the final event of the delay time Starting point of time) With induction blocking time (the default setting: 2.5S block time): sensor module, after each sensor output (high change Into a low level),you can set up a blockade followed by time period, in this time period the sensor does not accept any sensor signal. This feature can have a "sensor output time" and "blocking time" the interval between the work produced can be applied to detect the interval Products; also inhibit this function during load switching for a variety of interference. (This time can be set at zero seconds - Tens of seconds) The working voltage range: the default voltage DC4.5V-20V Micro-power consumption: static current "50 microamps, especially for battery-powered automatic control products The output high level signals: types of circuits can be easily and docking 3. Instruction Sensing module for about a minute after power initialization time, during the interval to the output module 0-3 times a minute in standby mode. Should avoid direct lighting such as interference sources close the surface of the lens module so as to avoid the introduction of interference signal generator malfunction; use of the environment to avoid the flow of the wind, the wind sensor will also cause interference. Sensor module using a dual probe, the probe's window is rectangular, dual (a per B million) in the direction of the ends of long, when the body passed from left to right or right to left when the reach the dual IR time, distance difference, the greater the difference, more sensitive sensors, when the body from the front to the probe or from top to bottom or from bottom to top direction passing, dual IR not detected changes in the distance, no difference value, the sensor insensitive or does not work; so the sensors should be installed dual direction of the probe with human activities as much as possible parallel to the direction of maximum to ensure that the body has been passed by the dual sensor probe. To increase the sensing range of angles, the module using a circular lens, the probe also makes sense on all four sides, but still higher than the upper and lower left and right direction of sensing range, sensitivity and strong, still as far as possible by the above installation requirements.VCC, trig (control side), echo (receiving end), GND 4. Dimensions and adjustment Note: The potentiometer clockwise to adjust the distance, sensing range increases (about 7 meters), on the contrary, sensing range decreases (about 3 meters).Delay adjustment potentiometer clockwise rotation, sensor delay longer (about 300S), the other hand, induction by the short delay (about 5S). 5. application a, Security Products b, the human body sensors toys c, the human body sensor lighting d, industrial automation and control, etc. It can automatically and quickly open various types of incandescent, fluorescent lamps, buzzer, automatic doors, electric fans,automatic washing machine and dryer Machines and other devices,is a hightech products. Especially suitable for enterprises, hotels, shopping malls, warehouses and family aisles, corridors and other sensitive Sense of region, or for the security zone automatic lighting, lighting and alarm systems. Shipping and Handling Payment: We accept the payment from Paypal only. If you really don't have the Paypal account you can contact us and we'll help you to solve the problem About tracking number: If the amount of your order is equal to or high than $25, your parcel will be sent out via registered service, or you need to pay $2.5 more for the tracking number. Shipping: We ship to Worldwide except Africa, Middle East, Caribbean countries. And as to the countries such as Russia, South America, if you place the order, we'll think that you accept that the shipping time might be longer, which usually takes about 45 days or more. It usually takes about 25-35 business days to the most of the countries in the world, except the countries mentioned above. Returning Policy: If you have problems about our products within 14 days after you receiving, according to the eBay Returning Policy, you can contact us and return the product back to us at your expense.We'll issue full refund for you after we receive the product in the original condition. Delivery Time Country Approx. Delivery time United States 7-21 working days Canada / United Kingdom / Australia 15-30 working days Italy / France / Spain / Germany/ Eastern Europe/Brazil / South America 30-40 working days
