2500' Pratt 250 250 3/0 250mcm Aluminum Urd Wire Direct Burial Xlp Use Cable

US $940

  • Millville, New Jersey, United States
  • Jun 24th
Store Home View All Listings Store Policies Feedback Contact Us /a> Sign up to receive our Clearance list of wire and cable. General Interest 2500' Pratt 250-250-3/0 250mcm Aluminum URD cable Wire Direct Burial XLP USE RHH Applications: Directly buried or installed inducts for 600 volt secondary distribution. Construction: Concentric stranded or compressed 1350-H19 aluminum conductors, crosslinked polyethylene insulation. Insulated conductors surface printed, neutral triple yellow striped. Two phase and one neutral conductor twisted together (LH lay) or parallel if so specified. Black neutrals may be specified if desired. Standards: Secondary UD triplex conductor 600V cable meets or exceeds the following ASTM specifications. B-230 Aluminum Wire, 1350-H19 for Electrical Purposes. B-231 Aluminum 1350 conductors, Concentric-Lay-Stranded. B-786 "19 Wire combination unilay-stranded Aluminum Conductors for subsequent insulation". B-901 "Compressed round stranded Aluminum Conductors using single input wire construction". Secondary UD triplex conductor 600V cable meets or exceeds all applicable requirements of ICEA S-105-692. "USE-2" per UL 854 available upon request. Options: Cable in Duct (CIC) Abrasion Resistant Ampacity: 90oC conductor temperature, 20oC ambient, RHO 50, 100% load factor for three conductor triplex with neutral carrying only unbalanced load. Technical data for cable with solid black neutral is identical to yellow extruded stripe data. All yellow extruded stripe cable is XLP insulation. To determine correct ampacity by conductor size, please consult the National Electric Code, latest edition. 2500' Pratt 250-250-3/0 250mcm Alum.URD Cable 600V USA Direct Burial XLP USE RHH Code Name Pratt Phase Conductor Phase Conductor Size AWG 250 Phase Conductor Stranding 37/w Phase Conductor Insulation Thickness 95 mls Neutral Size AWG 3/0 Neutral Stranding 19/w Neutral Insulation Thickness 80 mls Single Phase Conductor .748 Inches Outside Diameter 1.538 Inches Weight Per 1000ft 893 Lbs Ampacity Direct Burial 345 Amps Ampacity In Duct 265 Amps Free shipping on most orders. Ask About our Same Day and Next Day Shipping Methods For an Additional Fee. We accept PayPal and all major credit cards. All returns must be made within 30 days from the date of purchase or they will not be accepted. Feedback will be left as soon as feedback is left for us. Phone: 516-606-6537    Fax: 516-482-6438 Email: sales@nassaunationalcable.com
