25-50 Mhz Vco Rf, Voltage-controlled Oscillator.

US $390

  • default, Russian Federation
  • May 25th
Voltage-controlled oscillator VCO (25-50) MHz. Broadband Generator continuous harmonic signals in the frequency band: (25 ... 50) MHz. Control voltage: U = (0 ... 15) V. Output Power: (+12 ... + 16) dBm. The relative output of the second harmonic: -24 dBc. Output Impedance: Zout = 50 ohms. Supply voltage; E = (+ 7...+24) V, 100 mA Output RF connector: SMA Board size: 95 mm * 53 mm. Dependence of the voltage on the signal frequency. Uadj, (V). F1, (MHz) P1, (dBm) P2, (dBm) P3, (dBm) 0 24,6 +15 -6 -19 1 28,5 +16,0 -10 -12 2 30,9 +16,0 -10 -11 3 33,1 +16,0 -9 -11 4 35,1 +15,9 -8,5 -11 5 36,9 +15,9 -7,7 -11 6 38,9 +15,7 -7,2 -12 7 40,9 +15,6 -7 -11 8 43,1 +15,3 -7 -11 9 45,1 +15,1 -6,7 -11,7 10 46,9 +14,8 -7 -12 11 48,8 +14,4 -7,5 -12,6 12 50,1 +14,0 -8 -13 13 51,5 +13,8 -8,7 -13 14 52,4 +13,5 -9,3 -14 15 52,9 +13,4 -9,8 -14 15,3 53,1 +13,4 -10 -15
