200khz Benchtop Lcr/rcl/lcz Meter/tester

US $2900

  • Quebec, Quebec, Canada
  • May 9th
Open on mobile:
QR code
No need for it anymore, was bought to build my own transformers for a few projects. Physical body is excellent, no scratchs, no casing parts damaged. Features : - Primary Measurement: Capacitance / Inductance / Impedance - Secondary Measurement: D  Factor / Q  Factor / Rs (ESR) /Rp/ Phase Angle: - Measuring Range:  - Capacitance : 0.0000pF to 199.99mF;  - Inductance : 0.0000uH to 1999.9H;  - Impedance: 0.0000 ohm to 199.99M ohm;  - Resistance (ESR) : 0.0000mOhm  to  19,999KOhms;  - Dissipation factor ( D ) : 0.0000 to 19999;  - Quality Factor (Q ) : 0.0000 to 19999;  - Phase Angle: -180 to 179.99 degree;  - Overall accuracy : 0.1 % (1KHZ);  -  Test  Frequencies: 40Hz to 200KHz, manual 30 points selectable; and automatic mode;  -  Test voltage: 20mV, to 1.0Vrms, steps 20mV; . Equivalent circuit: series, parallel; . Zero calibration: Open, short; . DC bias voltage port: External, upto 35Vdc ( cable not supplied with );   . Display: 4 1/2 digits for LCZ ,Q & D measurement . 3 digits display for measurement frequency and signal level; . Measuring sample rate: Slow ,Fast; . AC Power :AC 110V /  220V /240V;   . Size / weight: app. 270(w) x 110(H) X 340(D) mm - Included: - English Operation Manual - 4 Wire Kelvin clip test leads, may need some rework/repairs (see photo), but still works ok. Ship to CANADA ans USA only   Buyers  you can ask me the shipping quote, it may be less than suggested by Ebay.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Zentech
Country/Region of Manufacture China
Model 1061
