Thousands of Used Metalworking and Plastic Machines & New Machine Tools Photos, Full Descriptions and Prices - Fast & Easy About Us Shipping Payments & Checkout FAQs Our Inventory Home CNC Machines Manual Lathes, Mills, Drills, Saws Grinders, Hones, Finishing Fabricating Equipment Presses & Feeds Boring Mills Automatic Screw Machines EDMs Inspection Equipment Air Compressors Plastic Machinery Planers & Planer Mills Broaches & Keyseaters Shapers & Slotters Tooling & Accessories Welding Equipment Wire & Fastener Ovens, Furnaces & Environmental Misc Metalworking Gear Machinery Material Handling Misc Non-Metalworking 2007 OKAMOTO 12" X 24" ACC-12-24DXNC-P CNC PROFILE & SURFACE GRINDER w/FANUC 21i 2007 OKAMOTO 12" X 24" ACC-12-24DXNC-P CNC PROFILE & SURFACE GRINDER w/FANUC 21i Ref #: 153601 iammdna XCNCSG 12" X 24" OKAMOTO "HIGH-PRECISION" CNC PROFILE SURFACE GRINDER WITH “FANUC 21i-MB” CNC CONTROL ** REPLACEMENT COST FOR THIS MACHINE IS OVER 170K AS EQUIPPED! HOLY COW! ** MODEL: ACC-12-24DXNC-P S/N: 63534 NEW: 2007 TABLE CAPACITY: NOMINAL GRINDING CAPACITY ....................... 12" x 24" MAXIMUM HEIGHT UNDER 12" WHEEL ...................... 13.6" LONGITUDINAL FEED (X AXIS): TABLE SPEED, INFINITELY VARIABLE ........... 3' TO 82' FPM MAX. LONGITUDINAL TABLE MOVEMENT, MANUAL ............ 26.0" FEED PER HANDWHEEL REVOLUTION ....................... 1.85" CROSSFEED (Z AXIS): MAX. SADDLE TRAVEL ................................... 9.0" INTERMITTENT TRAVERSE FEED .......... 0.002" TO 0.40" IPM GRINDING FEED .......................... 0.001" TO 40" IPM RAPID FEED ....................................... 40" IPM JOG FEED .................................... 0 TO 40" IPM MANUAL PULSE GENERATOR ............ 0.00001", .0001", .001" VERTICAL FEED (Y AXIS): GRINDING FEED .......................... 0.001" TO 40" IPM INTERMITTENT DOWN FEED .. ............ 0.00001" TO 0.004" RAPID FEED ....................................... 40" IPM JOG FEED .................................... 0 TO 40" IPM MANUAL PULSE GENERATOR ............ 0.00001", .0001", .001" GRINDING WHEEL: SPINDLE MOTOR ..................................... 5 H.P. WHEEL SIZE ......................... 12"DIA. x 1.5"W x 5"B SPEED ................................. 1,000 TO 3,600 RPM APPROX. DIMS. FOR OPERATION ........... 135" x 77"D x 95"H APPROX. MACHINE WEIGHT ........................ 6,000 LBS. EQUIPPED WITH: ASAHI RDU-WL DIAMOND ROTARY DRESSER OIL TEMPERATURE REGULATOR UNIT COOLANT SYSTEM WITH MAGNETIC SEPARATOR MACHINE TOOL ENCLOSURE MACHINE IS PRESENTLY WIRED FOR 3/60/230 VOLTS MACHINE FEATURES: CNC Unit (FANUC 21i-MB) Controlled Axis 2 Axis (2 SIM.) MIN. Increment Y - axis (Vertical) 0.00001” Z - axis (Saddle) 0.00001” MAX. Programmable Digits ±8 digits Grind Feed Rate Override 0 - 150% Rapid Feed Rate Override 0, 25, 50, 100 % Manual Pulse Feed Increments 0.00001, 0.0001, 0.001” Preparatory Functions M - Codes (2-digits) Automatic Acceleration/Deceleration Manual Continuous Feed Interpolation (Linear / Circular) Dwell Time Machine Lock Skip Function Stored Pitch Error Compensation Dry Run Single Block Self-Diagnosis Function Coordinate System Setting Pocket Calculator Type Decimal Point Programming Custom Macro B (Option) Inch / Metric Conversion Cutter Compensation C Input / Output Interface RS232C Part Program Storage Length (Total 262.5 FT) No. of Registered Programs: 63 Programs External Message Machine Features • Built-In Okamoto Conversational Programming System .... developed by Okamoto and based on our long experience with many different types of grinding applications. This software is based on the three basic types of grinding ... Form (Plunge), Surface, and Multiple-Step. The Conversational Programming promotes fast, easy set-up. Saves time...boosts productivity. When you need more flexibility in grinding, an RS232 Port and PC Card slot is available for G & M code programming transfer. • “Teach” Input Programming System ... Operator simply moves the grinding wheel manually to the grinding start position and using an input key teaches that position to the machine, then he moves the wheel to the cross reversal position and using the input key, teaches that position to the machine, etc. He then inputs stock removal, air cut, dressing interval, etc. and the control automatically calculates total movement and all start and stop points. • “Drawing” Input Programming System ... Input the actual dimensions from the workpiece drawing and the control automatically calculates the cycle sequence. • Built-In Conversational Dress Programming ... is based on the three basic types of dressing menus -- “Side”, “R”, “V”, and “SLOT”. “FREE” style may also be used utilizing “G” and “M” Code programming. All of the three basic types of dressing menus have the capability to dress the following forms. • Vertical & Cross Incremental Feed ... with Multipliers of 0.00001”/0.0001”/0.001”. • Automatic Lubrication...All DXNCP Models utilize a proven Gravity Feed Automatic Lubrication System. Lubrication oil is pumped to an oil reservoir located at the top of the column and is gravity fed to all guideway surfaces and positioning screws. • Extended Saddle and Table Ways ... Reduced overhand of the saddle and table at maximum limits provide long effective life of the machine tool and ensure its built-in accuracy. • Double-Walled Column Construction ... H-Shaped guideways with 3 tapered gibs provide the strength •Double Vee Way Table & Saddle Construction ... providing true tracking, greater table load support, and longer life of the built-in accuracy. ** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE ** ** EXCEPTIONAL CONDITION & APPEARANCE - ALL ORIGINAL - LOW HOURS ON MACHINE ** Machine Location: HARRISON, NJ Click Here For More Okamoto Machines Click Here For More Grinders, Lappers & Hones - CNC SURFACE GRINDERS(s) Questions about this Machine? Call Andy at (800) 873-6224 ext 7600 Need a Freight rate? Call Alex, our recommended trucking and shipping broker at (973) 732-3274 effepbdc Finance This Equipment For Your Business - Click Here Buy With Confidence Machinery Values is one of the world's largest machinery dealers, in business since 1971. All used items bought from our eBay store are covered by a standard MDNA (Machinery Dealer's National Association) 30 day return privilege, which means you can return an item you are dissatisfied with for a full refund. Please click on our MDNA return privilege link for complete details on how this works. New machines are covered under their own warrantees. Details of each warranty can be found within the quotation for all new machines. Most items in our store are located in our warehouse in Harrison, New Jersey - about 9 miles from New York City. You may inspect any item prior to purchase, under power in most cases, simply by calling and arranging an inspection. There is no charge for this. We are a Certified Square Trade Seller - click on the Square Trade logo for details. Questions? Call us at: (973) 497-7500 Shipping Policy Will ship to Worldwide. TOP Payments & Checkout We accept PayPal, Visa & MasterCard and American Express, or contact us regarding other payment options. Please contact us soon after the auction ends (or Buy-It-Now ends listing) to tell us how you wish to pay and get any shipping quotes or pickup information you may require. Call Terry at 973-497-7612 regarding payments, and Alex at 973-497-7613 for shipping questions. TOP Frequently Asked Questions We offer a 30 day return privilege on all used machines sold from our stock (machines sold for clients and shipped from their plant locations are generally not covered - so ask if you’re in doubt). This return privilege is the industry standard MDNA return privilege which states the machine must be returned freight prepaid in the same condition it was shipped in (you can’t break it then return it) for a full refund of your purchase price, excluding shipping costs. TOP
