2.4g Nrf24l01+pa+lna V5.1 16*32mm Wireless Module Without Antenna For Arduino

US $150

  • Shenzhen , China
  • Jan 29th
HOME New Arrivals Best sellers Daily Deals Help Desk Promotion News Store Categroy Store home Robots Raspberry Pi Wholesale Products Modules Development board Combination Items Breadboard DIY PCB Universal Board ICs & Processors Cables&Connectors Sensor Relay Crystal Oscillator Transistors Diodes Switch Battery & related Resistors&Potentiometers Tools Capacitor Inductor Digital tube Voltage regulator Fuse Buzzers&Speaker Helpful Links Store Newsletter Add my Store to your Favorites and receive my email newsletters about new items and special promotions! General Interest Hot Products title $16.90 title $1.96 title $1.59 title $1.75 title $3.20 title $5.35 title $7.90 2.4G NRF24L01+PA+LN A V5.1 16*32mm Wireless Module without Antenna for Raspberry pi   Description: The open area distance is about 1100m with Rate of 250K, 750m with the rate of 1M, 520m with the rate of 2M. NRF24L01P + PA + LNA wireless module operates in Free license 2.4G ISM band, you can do point to point application and can also be composed of star network. The Data transmission chip NRF24L01+, and match with the department's professional design, Add the the chip of power PA and LNA, RF switch, band pass filter composed of a professional full two-way RF power amplifier, making the effective communication distance has been greatly expanded. In the RF section, We has done a lot of debugging optimized match, making the highest emission efficiency, harmonic to be minimum. Increase the module stability. Small size: 45.54mm x 16.46mm, easy to embed in any space-constrained products, customers can add an MCU through the SPI port to control NRF24L01P + PA + LNA, Wireless module to complete long distance wireless data transmission system desige. Electrical parameters: Voltage:3-3.6 (3.3 best)V Maximum output power:+20dBm Transmit mode current (peak):115mA Receiving mode current (peak):45mA Power-down mode current:4.2uA Operating Temperature:-20~70C Receive 2Mbps mode:-92dBm Receive 1Mbps mode:-95dBm Receive 250Kbps mode:-104dBm PA Gain:20dB LNA Gain:10dB LNA noise figure:2.6dB Antenna Gain(peak):2dBI 2Mbps transmission distance (open):520m SHIPPING PAYMENT RETURNS FEEDBACK ABOUT US 1)All items will be shipped to your paypal address .Please update your latest address when you check out,and please make sure to provide us with correct,precise and detailed shipping address. 2)Most of the items will be shipped via Hongkong Airmail/Singapore Airmail .To US customers,we will send the package via E-packet . 3)All items will be shipped in 1-2 business days (excluding Sat,Sun & Holiday) after payment received and cleared. For the long-time holiday, we'll post the info on our store and reply you automatically via emails. 4)Tax:We will do our best to help you to clear the goods,and the tax depends on each country custom. 5)If you don't receive items over 30 business days,please make sure to contact us before leaving any neutral or negative feedbacks.We'll try our best to help you solve the problem. 6)The product in our store is free shipping. But the shipping method is different based on your order.If your order is more than $50 ,we will send the items to you with tracking number for free.If your order is less than $50,the registered mail fee is on your side. We could also deliver your item via EMS,DHL or Fedex based on your requirement. We Only Accept Paypal on Ebay. For specific requirements, please feel free to contact us. 1)If for some reason you're not satisfied with our service or product quality, please contact us within 3 days after you get the package, you can return the products to us in original package and we will refund your money after we get the package!(Shipping cost is NOT refundable and you should responsible for the return shipping) 2)Although we test each item and they are packed professionally, few item(less than 0.1%) might be damaged during the shipping. You are welcome to contact us within 3 days after you receive your package about replacement. 3)Repair Some items might be broken caused by improper use, we are always happy to offer any helpful repair service. Of course, you can send the broken items back to us and we will help you resolve the situation and charge reasonable repair fees. Feedback is important to all of us participating on the eBay community. We are always working hard for maintain high standards of excellence and strive for 100% customer satisfaction. So yourPOSITIVE FEEDBACK is very important. Here is an illustration showing how to leave the positive feedback, please follow the following step. Thank you so much. And welcome back to our store again. ICs_Processors_Store is a leading company specializes in all kinds of IC products, such as electronic devices and components, development modules, development boards, consumptive materials and so on. ICs_Processors_Store has gained thousands upon thousands of registered customers from all over the world. We offer world wide free shipping and have already shipped to more than 150 countries including United Sates, United Kingdom, Canada, Australia, France, Germany, Russia, Italy, New Zealand, Spain, Brazil, Japan, Singapore, Korean, etc. Here is a list of reasons for trusting ICs_Processors_Store as your reliable source of IC products or business cooperator: 1.Competitive Price 2.High Quality Products 3.Excellent R & D team 4.Excellent shopping platform 5.Excellent Customer Experience 6.Excellent Team Work In ICs_Processors_Store, we provide variety of IC products, sell them at the best price, and offer the best service.You will never regret to have ICs_Processors_Store as your reliable IC item source, supplier, and business cooperators. Have fun! Robots Wholesale Products Sensor DIY Power Modules Development board Wireless Module LCD Modules On Mar-19-14 at 20:27:26 PDT, seller added the following information: inkfrog terapeak i000000 inkFrog Analytics On Nov-26-14 at 09:06:06 PST, seller added the following information:
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Voltage 3-3.6 (3.3 best)V
Receive 1Mbps mode -95dBm
Maximum output power +20dBm
Receive 250Kbps mode -104dBm
Transmit mode current (peak) 115mA
PA Gain 20dB
Receiving mode current (peak) 45mA
LNA Gain 10dB
Power-down mode current 4.2uA
LNA noise figure 2.6dB
Operating Temperature -20~70°C
Antenna Gain(peak) 2dBI
Receive 2Mbps mode -92dBm
2Mbps transmission distance 520m
