1x Tot117 Tot-117 Matching Transformers Low Frequencies (ТОТ-117) Permalloy

US $620

  • Bulgaria, Bulgaria
  • May 24th
K&M Electronics Other Items In Our Store Feedbacks About Us Contact Us Add To Favorites 1x TOT117 TOT-117 Matching Transformers Low Frequencies (ТОТ-117) Permalloy Rated Power-1.0 W Input Voltage- 16X2 V Coefficient transformation +-5%: n1- 1.4 n2- 1.6 n3- 2 TOT-136 Transformers, low-frequency signal matching TOT-136 are designed for use in audio amplifiers domestic and industrial use, which are produced as separate assembly units or as part of consumer electronics. TOT-type transformers are used in devices of low-frequency paths formed on the semiconductor and other electronic devices in the equipment of printed circuit. TOT-type transformers are designed specifically for the printed wiring schemes. The pin pinout transformers like electronic devices and relays. There is a key and an additional marking of the first output on the side of the transformer (red dot). Counting findings made in a clockwise direction from the installation. This first conclusion is located in the upper left corner. Frame transformers gets additional rigidity by reinforcing its Snap, which is equal to the distance between the step grid of the PCB. Main specifications of the transformer type TOT: • The operating range effectively Frequency ...... 300 ... 10000 Hz; • The range of rated power ...... 0.025 ... 25 V * A; • ...... resonant frequency less than 1000 Hz; • The maximum value of the test voltage ...... 500; • Distortion on the cut-off frequency bandwidth of 300 Hz ... 10000 ...... no more than 5%; • ratio of the amplitude-frequency distortion in the frequency range 300 Hz ... 10000 ...... ± 2 dB; • The maximum amplitude of the AC input voltage transformers ...... 140; • Setting range of input impedances of transformers ...... 13 ... 22000 ohms; • The maximum voltage of the primary winding ...... 100 V; • Load impedance transformers ...... 4 ... 4000 Ohm; • The maximum DC voltage on the windings of the transformer ...... 100 V; • The insulation resistance between the windings and between each winding and the yoke ...... 1000 ohm; • The maximum deviation of the transformation ratio ...... ± 5%; • Ambient ...... -60 ... + 125 ° C.                                                                                                                                                                                                                                                                             We accept payment through PayPal.     You can shop with confidence. We have fast and professional customer support. We offer combined shipping and have value insured deliveries from our carrier. The order will be processed within 12-36 hours after payment is received. We make deliveries by registered airmail with priority, tracking number and recommendation. The average delivery times are: Europe: 8 to 14 business days All other destinations: 12 to 22 business days.
