1pcs Multifunction Relay Cycle Module Automation Delay Timer Switch Frm01 12v

US $9.65

Singapore, Singapore
Jan 29th

Open on mobile:
QR code

Shipping Payment Return Policy&Feedback Contact Us Product Show Desription 100% Brand New And High Quality User can select from below eight functions, by using the key buttons onboard. User can select and save the set parameters. The set time is 1 second at minimum, and precision is better than 0.1 second. The eight functions are as follows: 1) Close upon the set time: after power one, the delay time T1 reaches, and the relay closes. T1 is adjustable between 0 second to 270 hours. When we feed CH1 a high level pulse signal, the cycle repeats itself (the high level time lasts longer or equal to 20ms. Same applies to below). 2) Disconnect upon the set time: when the relay closes, the delay time T1 reaches, and the relay opens. T1 is adjustable between 0 second to 270 hours. When we feed CH1 a high level pulse signal, the cycle repeats itself. 3) Cycle Mode 1: after power on, the relay does not close at first. When T1 reaches, the relay closes. When T2 reaches, the relay opens. And the cycle goes on. T1 and T2 adjustable between 0 second to 270 hours. When we feed CH1 a high level pulse signal, the cycle repeats itself. 4) Cycle Mode 2: after power on, the relay immediately closes. When T1 reaches, relay opens; when T2 reaches, the relay closes again, and the cycle goes on. When we feed CH1 a high level pulse signal, the cycle repeats itself. 5) Self-lock relay mode: we feed CH1 a high level pulse signal, relay closes. When we again feed a high level pulse signal, the relay opens. 6) Trigger relay mode: we feed CH1 a high level signal, relay closes. When the high level finishes, the relay opens. 7) Limited cycle mode 1: on basis of function 3, we increase the cycles. Under this mode, T1 and T2 are adjustable between 0 second to 9999 second, the cycle is selectable between 1 to 9999 times. 8) Limited cycle mode 2: on basis of function 4, we increase the cycles. Under this mode, T1 and T2 are adjustable between 0 second to 9999 second, the cycle is selectable between 1 to 9999 times. Connections: Control Side: 1) DC+ : 12V positive 2) DC-: power in negative 3) CH1: signal input Output side: 1) NO: normal open (before relay closes, this pin is not connected. after relay closes, the pin short-connects with COM) 2) COM: Common 3) NC: Normal closed (before relay closes, this pin short-connect with COM. after relay closes, the pin is not connected ) 1pcs Multifunction Self-lock Relay Module Shipping Item will be shipped within 24 -48 hours after full payment is received. The Item will be shipped by air mail,Normally the shippment to worldwide is used to take 20 to 25 business days, exclude Sat & Sun. Payment We only accept payment through Paypal. Payment must be received in 7 business days of auction closing. Please leave note for your special request in ebay note when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Return Policy&Feedback If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 3 months, you can return it to us. We will send you a new replacement after receiving the defective item Contact Us We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply your email as soon as possible, please kindly allow 24 hours(working day) for us to response. Thank you. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative or neutral feedback without any contact
