16 Ch Digital Eeg Mapping System Brain Electrical Activity Mapping + 2 Tripod

US $1,108.00

Qinhuangdao,Hebei, China
Jan 30th

Open on mobile:
QR code

CONTEC™ Erin Commercial Manager Contec Medical System Co., LTD #112 Qinhuang West Street Qinhuangdao E&T Development Zone Hebei Province P.R. China Email: contecdb@gmail.com Skype: erin.gao0118 ebay Store: contecmedical2010 Description Introduction KT88 Digital Brain Electric Activity Mapping is an equipment for checking 16 channels of EEG and optional 2 channels of ECG, it collects EEG signal with electrodes, via integrated amplification, A/D transformation, PC auto-analysis, FFT, to form electroencephalogram which displays with color depth. The product is applicable for checking such diseases as epilepsy, intracranial inflammation, cerebrovascular diseases and brain tumors. Performance Parameter Channel: 16 channels of EEG + 2 channels of ECG(ECG is optional) Sampling rate: 100 Hz A/D transformation: 12 bits Input impedance: >=10M? Patient leak current: < 10µA Noise level: =90dB Magnification multiple: 10000 Filter constant: all digital and free enactment Display speed(paper speed): 5, 10, 15, 30, 60, 120 mm/s Amplitude: 1, 1.5, 2, 3, 5, 7.5, 10, 12, 15, 20, 30, 50 mm/50µV Playback speed: 1 time, 2 times, 3 times, 10 times, 20 times, 40 times, 60 times 50Hz interference suppression: >=30dB Safety type:Class II, type BF applied part Function Features Standard 16 channels of EEG, compatible with 16 channels and 8 channels function. Method of 10/20 electrodes placement under international standard system, montages can be changed during replaying(such as monopolar, bipolar or user-defined montages). Adopt bioelectricity amplifier for distilling brainwave, continuous record time can be up to 24 hours, integrated full-automatic calibration system. Powerful playback function: two playback modes(continuous and rolling) are optional, amplitude and display speed are adjustable. The special subdividing time line divides the waveform in one second into 5 parts, which is easy for doctors to look over the waveform. Multifunctional digital filter system provide different filter methods and window types, and user can freely set low-pass, high-pass, band pass and band stop filter. EEG signal clipping function, analyze and store any section of EEG wave, and select several segments waveforms for automatically analyzing and distilling to different parameters. Electronic frequency ruler, convenient to measure the basic information of any appointed EEG waveforms. With partial enlarging window, to accurately measure EEG period, amplitude and frequency, and which can be adjusted according to personnel judgment. Mark EEG wave under the events of opening eyes, closing eyes and flashing with different colors, and user-defined events can be added, waveform color for evoked event can also be set freely, ensures that the waveform in corresponding time can be rapidly found by event name during case playback. Powerful automatic analysis function, can carry through the power spectrum analysis and pathologic wave detection for appointed waveform. Many graphs can be displayed in the same screen, including kinds of BEAM, numerical BEAM, compressed spectrum graph, trend graph, and so on. Professional isolation transformer, dual power supply isolation system and optoelectronic data transmission to ensure security. Use USB interface to transmit data which just need to be inserted. Multifunctional flash stimulator of USB interface, and frequency can be controlled manually or automatically. A flash stimulation scheme can be set and performed in the process of collection. Perfect case management function, provides many means for research and quick statistic information; convenient case export and import function, and stores with CD-RW disk, which is easy for data research. Integrative image and character report, report can be edited in mode and switched to Word document. Case files can be transformed into EDF and BDF data format, convenient for data exchange, academic exchange and further analysis. System parameters and display modes can be set as required, which meets different user’s requirements. Add marks and annotations to the waveform designated, which can rapidly find the waveform in that time by marks. Optional video function: USB camera is easy to install, convenient to use and exact to record. With flexible playback function, which can browse the waveform of any time along with the corresponding isochronous collected image. SpO2 function which can view SpO2 value, pulse rate and SpO2 trend graph is optional. Accessories Standard accessories: Twenty EEG leads Two EEG leads(ear electrode) Two data lines Twenty EEG electrodes Two headgears One flashlight One flashlight power supply One disk One User Manual One earth wire Two aluminum blocks Optional accessories: ECG lead. ECG electrode(for optional ECG function) SpO2 module (one CMS-P SpO2 probe, one disk with software) Video module(one softdog, one camera, one video software disk) EEG bracket(tripod) Qualification Certificate SFDA, CMC About Payment PAYPAL Bank transfer About Shipping 1?We only ship to the confirmed address provided by PayPal. Before you pay, please make sure your address in PayPal matches the address you would like us to ship to. 2. We strive our best to provide you the most reliable, affordable way of shipping service. But sometimes international delivery is highly depended on the courier company and local customs/duties. If you do not receive your item on time, please contact us immediately for further assistance. Thank you for your understanding. 3. We offer combined shipping which will save your shipping cost greatly for your multiple purchases. Please do not pay until you make your last purchase. 4. We are unable to take any responsibility for any custom delay or tax. Reason is because transit time is highly depended and provided by Postal Service (except weekends and holidays) 5. The Tracking Web? http://www.17track.net/index_en.shtml You can also contact us for the shipping details . About Item All items sold by us are being described to the best of our abilities, as accurate as possible, and with utmost conscientiousness on our part. However, to avoid any potential oversights, I respectfully request your assistance in helping us to make this a mutually satisfactory transaction by THOROUGHLY reviewing item description and photos, and asking all questions PRIOR TO BIDDING. **Please Note that size and color representation are subject to manufacturing variance and may not be exact. Also note that monitor settings may vary from computer to computer and may distort actual colors. Please read these terms thoroughly before placing your bid. Terms & Condition The item is sold on an "as is" basis, please ask all questions before bidding to avoid getting an item you are not satisfied with. Returned item has to be new, unworn and in its original condition. Item must be returned in its original and unused condition and Never mounted. Open box merchandise is subject to a 30% Restocking fee. Return / Refund Accept Return is accepted within 7 days after the buyer's receiving the item. If this item is defective upon receipt, customer has up to 7 days from date of receipt for exchange of a new one. If you are not completely satisfied with your purchase, you may return it to us for a prompt exchange or we will refund your payment. Unused/unopened merchandise will be fully credited. Please note that all purchases must be returned within 14 days of purchase. NO return or exchange will be accepted after 14 days from the date of purchase. Include your name, address, item, daytime telephone, how you paid, and if you are requesting a refund or exchange. After getting the returned item, we will refund the customer at the item's price ( excluding the shipping costs to and fro ). Return / Refund Not Included Delivery fees will not be refunded. Please understand that shipping and handling fee is not refundable. Buyer is responsible for shipping costs incurred shipping products back. In no circumstances is Shipping, Handling & Insurance refunded. Customer Satisfactory Note: Do not hesitate to contact us anytime before and after your purchase, we are committed to your 100% customer satisfaction. We back our commitment with superb service, full money back and a customer satisfaction guarantee. I am here and ready to assist you with any questions or concerns you might have before or after the purchase. My goal is to make sure you are a happy customer and pleasant shopping with us. When you shop with us, your satisfaction is our #1 priority. Bid With Confidence! Buy Safe Product: The following FDA Disclaimer is required for all eBay listing in Healthcare category and is included for REFERENCE: The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject toFDA regulation,we will verify your status as an authorized purchaser of this item before shipping of the item. The EEG Mapping System registered on the Australian Register of Therapeutic Goods (ARTG) with the code 197923, and certified by FDA of United States and by CE,TUV of Europe.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Contec
MPN	KT88
Model	EEG Mapping System
Country/Region of Manufacture	China
