10' Laserline Direct Elevation Rod In 10ths Surveying Contractor Grade Lenker

US $870

  • Opa-Locka, Florida, United States
  • May 28th
                                                                             Providing 10 years of experience in the business Setting the Standards Yesterday, Today & Tomorrow Giving you the quality service you deserve                                                                                                                                                       LaserLine GR10T 10' Lenker Style Direct Reading Rod 10ths                                                          The GR10T 10' Lenker Style direct reading level rod, gradations in feet/tenths, allows you directly observe the true elevation of any point on the job site without any performing any calculations.  For use with optical levels (for use with a laser and detector, use a direct reading laser rod such as the GR1000 or GR1000T which have a track allowing you to slide the detector up and down).  Simply set the reading on the rod to match the elevation of a known elevation such as a benchmark or hub. This is possible because the rod face is actually a continuous flexible tape mounted on rollers within the frame of the rod which can be locked down once set. From then on, every elevation reading around the job site can be read directly through your optical level.  FEATURES:  The Laser Line GR10T Direct Reading grade rod is made of high strength clear anodized aluminum for lightweight rugged, dependable operation. It will not rust, split, splinter swell or warp in any environment.  The tape has a heavy duty matte textured face which is easy on the eyes in bright sunlight and protects the tape numbers from wear and fading.  Tape lock grommets are over sized,  heavy duty brass. This greatly minimizes the problem of tape tearing.  Detector rail is black, high density, U.V.stabilized for long life. It is specifically designed to not become brittle when exposed to ultraviolet rays or direct sunlight.  The solid tape lock has an internal brake slide for stronger, trouble-free operation.            \\\\\\\\\\\\\\\\\\\\\   DIRECTIONS FOR USING THE GR10T DIRECT READING ROD:  1. Set rod foot on a benchmark or hub with a known elevation; i.e. 2,525.25 elevation.  2. Using an optical instrument, (sight level, auto level, etc.) sight to the rod and use the horizontal line as your grade reference.  3. Loosen the tape lock pin (lower knob) and disengage the tape pin from the grommet.  4. Roll the tape face until 5.25 is the horizontal line on your optical instrument. You are using the last whole number and the decimal numbers of 2,525.25.  5. Lock the tape by engaging the tape lock pin into the nearest grommet. Then tighten the knob. You have now locked into the rod elevation (2,525.25). All future readings will be true elevation above or below 2,525.25 (5.25).  6. To find an elevation, simply set the rod foot at any location on the job within the range of your optical instrument. Using your optical instrument, just read the number across the horizontal line. That number is your true elevation.  EXAMPLE:  Rod reading is 6.10 = 2,526.10 true elevation  Rod reading is 8.32 = 2,528.32 true elevation  Rod reading is 4.70 = 2,524.70 true elevation                                                                                                                                                           Shipping Details                Item will be shipped via First-Class.                    Item will generally ship within 3 days of cleared payment.                    Tracking information for this item will automatically be uploaded when it has been shipped                    Orders are shipped from our facilities in Miami, Florida.                                                                         Payment Details                                                                                           Payment is due within 3 days of purchase, after which transactions will be sent to an Unpaid Item Dispute. If you need more time to complete payment, please let us know and we will be happy to work with you.                  We accept Paypal, Checks, & Money Orders. Items purchased by E-Check, Check, or Money Order will be shipped when payment has cleared.                                                                        Return Policy                             Unwanted Returns for this item are not accepted.              Defective Returns for this item are accepted within 14 days. Unfortunately, we cannot refund the cost of shipping.       In order to initiate a return, Buyer MUST notify us prior to shipping back the defective item so that we may issue an RMA number. After we have been notified, Buyer must ship back the defective item within 7 days of being issued an RMA in order to receive a full refund.                  International Buyers                                               This item is eligible for standard International shipping.                      Hours of Operation                                                                                              Our hours of operation are Monday-Friday from 8 am. to 5 pm. EST.                    If you have any questions, we do our best to answer you in a timely manner.                               Skype: tsinstruments Email: info@tsinstruments.com Phone: 786-300-1TSI(874)
