(1 PC) 54LS253DMQB FSC DUAL 4 LINE TO 1 LINE MULTIPLEXER, TRUE OUTPUT, CDIP16, US $7.00 – Picture 0
(1 PC) 54LS253DMQB FSC DUAL 4 LINE TO 1 LINE MULTIPLEXER, TRUE OUTPUT, CDIP16, US $7.00 – Picture 0

(1 Pc) 54ls253dmqb Fsc Dual 4 Line To 1 Line Multiplexer, True Output, Cdip16

US $7.00

  • Granbury, Texas, United States
  • Feb 17th
Open on mobile:
QR code
THIS LISTING IS FOR (1 PC) OF 54LS253DMQB DUAL 4 LINE TO 1 LINE MULTIPLEXER, TRUE OUTPUT, CDIP16 SPECIFICATIONS Mfr Package Description CERAMIC, DIP-16 Status Discontinued Logic IC Type MULTIPLEXER Sub Category Multiplexer/Demultiplexers Family LS JESD-30 Code R-GDIP-T16 Load Capacitance (CL) 45 pF Max I(ol) 0.0120 Amp Number of Functions 2 Number of Inputs 4 Number of Outputs 1 Number of Terminals 16 Operating Temperature-Min -55 Cel Operating Temperature-Max 125 Cel Output Characteristics 3-STATE Output Polarity TRUE Package Body Material CERAMIC, GLASS-SEALED Package Code DIP Package Equivalence Code DIP16,.3 Package Shape RECTANGULAR Package Style IN-LINE Power Supplies (V) 5 Power Supply Current-Max (ICC) 12 mA Prop. Delay@Nom-Sup 25 ns Propagation Delay (tpd) 32 ns Qualification Status MILITARY Screening Level 38535Q/M;38534H;883B Seated Height-Max 5.08 mm Supply Voltage-Nom (Vsup) 5 Supply Voltage-Min (Vsup) 4.5 V Supply Voltage-Max (Vsup) 5.5 V Surface Mount NO Technology TTL Temperature Grade MILITARY Terminal Finish NOT SPECIFIED Terminal Form THROUGH-HOLE Terminal Pitch 2.54 mm Terminal Position DUAL Length 19.43 mm Width 7.62 mm
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand FAIRCHILD SEMICONDUCTOR
Country/Region of Manufacture Indonesia
MPN 54LS253DMQB
